ROTOR DISC » RN1348V

RN1348V

Specification

Type
Vented
Disc Thickness (Max)
28
Num. of holes
5
Height
47.8
Centering Diameter
69
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
300
Drum Ø:
143
Disc Thickness (Min)
25
Structure Material
G3000

Cross Reference

HYUNDAI
51712-0Z000
HYUNDAI
51712-1M500
HYUNDAI
51712-2Y000
HYUNDAI
51712-3K100
HYUNDAI
51712-3K110
HYUNDAI
51712-3K150
HYUNDAI
51712-3K160
HYUNDAI
51712-3K300
HYUNDAI
51712-3Q000
HYUNDAI
51712-A0000
HYUNDAI
51712-M0500
HYUNDAI / KIA
51712-A0000
HYUNDAI / KIA
51712-A0100
KIA
51712-0Z000
KIA
51712-1M500
KIA
51712-2Y000
KIA
51712-3K100
KIA
51712-3K110
KIA
51712-3K150
KIA
51712-3K160
KIA
51712-3K300
KIA
51712-M0500
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   Creta

06.15~06.18 1400 D4FC PA016 RHD RN1348V PN0799 FN0799
06.18~08.20 1400 D4FC PA018 RHD RN1348V PN0799 FN0799
12.19~ 1500 D4FA PFH20 RHD RN1348V PN0799 PN0538
12.19~ 1500 G4FL PFH20 RHD RN1348V PN0799 PN0538
07.15~06.18 1600 D4FB PA016 LHD RN1348V PN0799 FN0799
07.15~06.18 1600 D4FB PA016 RHD RN1348V PN0592 FN0799
08.16~05.21 1600 G4FG M017 RU RN1548VRN1348V PN0373 RN2086RN1549 PN0436
07.15~06.18 1600 G4FG PA016 LHD RN1348V PN0799 FN0799
07.15~06.18 1600 G4FG PA016 RHD RN1348V PN0799 FN0799
06.18~08.20 1600 G4FG PA018 LHD RN1348V PN0799 FN0799
06.18~08.18 1600 G4FG PA018 RHD RN1348V PN0799 FN0799
07.21~ 1600 G4FG PFZ21 RN1562VRN1348V PN0799PN0958 RN1549RN2233RN1601 PN0538
08.16~05.21 2000 G4NA M017 RU RN1348V PN0373 RN1549RN2086 PN0436
03.20~10.21 2000 G4NA M017 RU RN1548VRN1348V PN0373 RN1549RN2086 PN0436
12.19~ 2000 G4NL PFH20 LHD GRAND 7P RN1348V PN0799
07.21~ 2000 G4NL PFZ21 RN1348V PN0799 RN1601RN2233RN1549 PN0538

HYUNDAI   »   i40

01.15~01.18 1600 G4FD PDF15 SDN LHD RN1348V PN0052 RN1556 PN0538
02.11~06.15 1700 D4FD DF RN1348V PN0052 RN1556 PN0538
02.11~06.15 2000 G4NA PDF12 WGN LHD RN1348V PN0052 RN1556 PN0538
02.11~06.15 2000 G4NA PDF12 WGN RHD RN1348V PN0052 RN1556 PN0538
01.15~01.18 2000 G4NA PDF15 SDN LHD RN1348V PN0052 RN1556 PN0538
02.11~06.15 2000 G4NC LC81 RN1348V PN0052 RN1556 PN0538

HYUNDAI   »   i45

01.10~04.14 2400 G4KJ EC41 ARL RN1348V PN0052 RN1476 PN0426 FN11008

HYUNDAI   »   iX 35

01.14~06.15 1600 G4FD TMZ10 LHD RN1348V PN0052 RN1307 PN0436 FN11006
05.13~01.16 2000 D4HA PTM14 RHD RN1348V PN0052 RN1307 PN0436 FN11006
10.09~08.13 2000 D4HA TM10 AUS RN1348V PN0052 RN1176 PN0436 FN11006
01.10~08.13 2000 D4HA TMZ10 LHD RN1348V PN0052 RN1176 PN0436 FN11009
07.13~06.15 2000 D4HA TMZ14 RUS RN1348V PN0052 RN1176 PN0436 FN11009
11.09~06.15 2000 G4KD LM RN1348V PN0052 RN1176 PN0436 FN11009
11.09~08.13 2000 G4KD TM10 LHD RN1348V PN0052 RN1176RN1307 PN0436 FN11006FN11009
11.09~08.13 2000 G4KD TM10 RHD RN1348V PN0052 RN1307RN1176 PN0436 FN11006FN11009
08.09~09.13 2000 G4KD TMZ10 RUS RN1348V PN0052 RN1307RN1176 PN0436 FN11006FN11009
07.13~06.15 2000 G4NA TMZ14 RUS RN1348V PN0052 RN1307RN1176 PN0436 FN11009FN11006
11.10~12.15 2400 G4KE LM RN1348V PN0052 RN1176 PN0436 FN11009

HYUNDAI   »   Sonata

11.10~01.15 2400 G4KK PGFE11 GL RN1348V PN0536 RN1476 PN0591 FN0716

HYUNDAI   »   Sonata 04

09.06~12.07 2000 D4EA NF04 RHD RN1348V PN0377 RN1476 PN0539PN0591 FN11004
09.04~09.06 2000 D4EA PA04 LHD RN1348V PN0377 RN1476 PN0539 FN11004
09.04~12.07 2000 G4KA NF RN1174VRN1348V PN0377 RN1386RN1476 PN0539 FN11004

HYUNDAI   »   Sonata 08

12.07~01.13 2000 D4EA NF RN1348V PN0377 RN1476 PN0591 FN11004
12.07~10.10 2400 G4KE EU41 LHD RN1348V PN0377 RN1476 PN0591 FN11004
12.07~10.10 3300 G6DB NF RN1348V PN0377 PN0539 FN11004

HYUNDAI   »   Sonata 10

09.09~06.14 2000 G4KH PGFA10 US RN1348V PN0536 RN1476 PN0591 FN0716
07.12~04.14 2000 G4NE YF RN1348V PN0536 RN1476 PN0591 FN0716
09.09~07.12 2400 G4KJ PGFA10 US RN1348V PN0536 RN1476 PN0591 FN0716
09.09~03.14 2400 G4KJ YF RN1348V PN0536 RN1476 PN0591 FN0716
11.10~07.12 2400 G4KK PGFE11 US RN1348V PN0536 RN1476 PN0591 FN0716

HYUNDAI   »   Tucson 04

10.06~12.09 2000 D4EA JM04 LHD RN1348VRN1174V PN0377 RN1176 PN0591PN0539 FN0644
10.06~12.09 2000 G4GC JM04 LHD EU RN1174VRN1348V PN0377 RN1386RN1176 PN0591PN0539 FN11004FN0644

HYUNDAI   »   Tucson 10

10.09~08.13 2000 D4HA TM10 LHD RN1348V PN0052 RN1176RN1307 PN0436 FN11009FN11006
10.09~08.13 2000 D4HA TM10 RHD RN1348V PN0052 RN1176 PN0436 FN11009FN11006
11.09~08.13 2000 G4KD TM10 LHD RN1348V PN0052 RN1176RN1307 PN0436 FN11006FN11009
11.09~08.13 2000 G4KD TM10 RHD RN1348VRN1174V PN0704PN0052 RN1307 PN0436 FN11006
10.09~08.13 2400 G4KE TM10 LHD GL RN1348V PN0052 RN1176 PN0436 FN11009
10.09~08.13 2400 G4KE TM10 LHD US RN1348V PN0052 RN1176 PN0436 FN11009
10.09~08.13 2400 G4KE TM10 RHD RN1348V PN0052 RN1176 PN0436 FN11009

HYUNDAI   »   Tucson 14

08.13~05.15 2000 D4HA PTM14 LHD RN1348V PN0052 RN1176 PN0436 FN11006FN11009
08.13~06.15 2000 G4NA PTM14 LHD RN1348V PN0052 RN1176RN1307 PN0436 FN11009FN11006
08.13~05.15 2000 G4NA PTM14 RHD RN1348V PN0052 RN1176RN1307 PN0436 FN11009FN11006
08.13~06.15 2400 G4KE PTM14 LHD RN1348V PN0052 RN1176 PN0436 FN11009
08.13~06.15 2400 G4KE PTM14 RHD RN1348V PN0052 RN1176 PN0436 FN11009
08.13~06.15 2400 G4KJ PTM14 US RN1348V PN0052 RN1176 PN0436 FN11009

HYUNDAI   »   Veloster

03.11~01.15 1600 G4FJ PGS11 US RN1348V PN0739PN11001 RN1549 PN0538
01.15~02.18 1600 G4FJ PGS15 US RN1348V PN0739 RN1549 PN0538

KIA   »   Carens 12

01.13~09.16 1600 G4FD HU81 RHD RN1348V PN0799 RN1947 PN0538
12.12~08.16 1700 D4FD WAGON - 5DR 7P RN1348V PN0799 RN1947 PN0538
01.13~ 2000 G4NA MPV LHD RN1348V PN0799PN0537 RN1947 PN0538
01.13~09.16 2000 G4NC HU RN1348V PN0799 RN1947 PN0538
01.13~09.16 2000 G4ND RPA412 RN1348V PN0799 RN1947 PN0538
01.13~09.16 2000 L4NA DOMPA412 RN1348V PN0799 RN1947 PN0538

KIA   »   Carens 16

08.16~07.18 1700 D4FD WAGON - 5DR 7P RN1348V PN0537 RN1947 PN0538

KIA   »   Cee'd

05.15~07.18 1000 G3LC HB/SW/PRO RN1562VRN1348V PN0592PN11001PN0537 RN1563RN1549 PN6148PN0538
03.12~07.18 1400 D4FC HB/SW/PRO RN1348VRN1562V PN0537PN0592PN11001 RN1549RN1563 PN0538PN6148
03.12~07.18 1600 D4FB HB/SW/PRO RN1562VRN1348V PN0592PN11001PN0537 RN1563RN1549 PN0538PN6148

KIA   »   Cerato III Forte Coupe

01.13~03.16 1600 G4FJ FZ61 LHD RN1348V PN0739 RN1549 PN0538
01.13~03.16 1600 G4FJ FZ61 RHD RN1348V PN0739 RN1549 PN0538

KIA   »   Forte

02.13~02.16 1800 G4NB FX4A SDN US RN1348VRN1562V PN0739PN0537 RN1549 PN0538

KIA   »   K5

05.10~06.13 2400 G4KJ PTF11 RN1348V PN0536 RN1476 PN0591 FN0716

KIA   »   Optima

05.18~10.19 1600 D4FE SDN EU RN1348V PN0052 RN1601 PN0538
05.18~ 1600 D4FE WGN EU RHD RN1348V PN0052 RN1601 PN0538
03.10~03.14 2000 G4NE PTFE11 RN1348V PN0536 RN1476 PN0591 FN0716
03.14~03.16 2000 G4NE PTFE14 RN1348V PN0536 RN1601 PN0538

KIA   »   Optima (USA)

03.10~09.13 2400 G4KJ PTF11 RN1348V PN0536 RN1476 PN0591 FN0716
12.11~09.13 2400 G4KJ TFA12 RN1348V PN0536 RN1476 PN0591 FN0716
04.13~02.16 2400 G4KJ TFA14 RN1348V PN0536 RN1476 PN0591 FN0716
04.13~02.16 2400 G4KK PTFE14 RN1348V PN0536 RN1476 PN0591 FN0716
03.10~09.13 2400 G4KK TF RN1348V PN0536 RN1476 PN0591 FN0716

KIA   »   Rondo

01.13~12.17 1700 D4FD HU81 RN1348V PN0799 RN1947 PN0538

KIA   »   Seltos

06.19~ 1400 G4LD PTI20 RN1348V PN0799 RN1549 PN0538
06.19~ 1600 G4FG PTI20 LHD RN1348V PN0799 RN1549 PN0538
06.19~ 1600 G4FG PTI20 RHD RN1348V PN0799 RN1549 PN0538

KIA   »   Sportage

08.10~04.14 1700 D4FD SL RN1348V PN0052 RN1176 PN0436 FN11009
01.14~03.16 1700 D4FD SL RN1348V PN0052 RN1176 PN0436 FN11006FN11009
04.08~07.10 2000 D4EA FQZ ER RN1348V PN0052 RN1176 PN0436 FN11009
08.10~04.14 2000 D4HA PSL10 LHD KDOM RN1174VRN1348V PN0052PN0704 RN1307 PN0436 FN11009FN11008
09.09~04.14 2000 D4HA PSL10 RHD RN1348V PN0052 RN1307 PN0436 FN11008
08.10~04.14 2000 D4HA SLZ10 LHD RN1348V PN0052 RN1176 PN0436 FN11009
08.10~04.14 2000 G4KD PSL10 RHD RN1348VRN1174V PN0704PN0052 RN1176RN1307 PN0436 FN11009FN11008
08.10~10.15 2000 G4KD SL10 LHD RN1174VRN1348V PN0052PN0704 RN1176RN1307 PN0436 FN11008FN11009
06.10~04.14 2000 G4KD SLZ10 LHD RN1348V PN0052 RN1176 PN0436 FN11009
08.10~04.14 2400 G4KE PSL10 LHD RN1348V PN0052 RN1307 PN0436 FN11008FN11009

KIA   »   Sportage 14

01.14~03.16 2000 D4HA SL14 RN1348V PN0052 RN1176RN1307 PN0436 FN11009FN11008
01.14~03.16 2000 D4HA SLZ14 ER RN1348V PN0052 RN1176 PN0436 FN11009
01.14~03.16 2000 G4NA PSL14 RHD RN1348V PN0052 RN1307 PN0436 FN11008
01.14~03.16 2000 G4NA SLZ14 RN1348V PN0052 RN1176 PN0436 FN11009
01.14~03.16 2400 G4KE SL14 RN1348V PN0052 RN1176 PN0436 FN11009
