ROTOR DISC » RN1643
Specification
Type
Solid
Outter Ø
300
Num. of holes
5
Disc Thickness (Max)
10
Height
25
Centering Diameter
76
Pitch Circle Ø
114.3
Front/Rear
Rear
Disc Thickness (Min)
8.4
Structure Material
G3000
Drum Ø:
155
Cross Reference
HYUNDAI
58411-3Z700
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.18~ | 1600 | G4FD | PDF18 | PN0052 | RN1556RN1643 | PN0538 | ||
| 02.11~09.17 | 1600 | G4FD | VF | RN1644V | PN0052 | RN1556RN1643 | PN0538PN0591 | |
| 02.11~06.15 | 1700 | D4FD | LC81 WGN LHD EU | RN1644V | PN0052 | RN1643 | PN0538 | |
| 02.11~06.15 | 1700 | D4FD | LC81 WGN LHD KDOM | RN1644V | PN0052 | RN1643 | PN0538 | |
| 01.15~01.18 | 1700 | D4FD | PDF15 SDN LHD | RN1644V | PN0052 | RN1643 | PN0538 | |
| 01.15~01.18 | 1700 | D4FD | PDF15 SDN RHD | RN1644V | PN0052 | RN1643 | PN0538 | |
| 02.11~06.15 | 2000 | G4NA | PDF12 SDN LHD | RN1644V | PN0052 | RN1643 | PN0538 |
