ROTOR DISC » RN1548V
Specification
Type
Vented
Outter Ø
280
Num. of holes
5
Disc Thickness (Max)
23
Height
44.2
Centering Diameter
69
Pitch Circle Ø
114.3
Front/Rear
Front
Drum Ø:
143
Disc Thickness (Min)
21.4
Structure Material
G3000
Hole Ø:
12.6
Notes
15" 2WD
Alternative
Cross Reference
HYUNDAI
51712-2V000
HYUNDAI
51712-3X000
HYUNDAI
51712M0000
HYUNDAI / KIA
51712-3Y000
HYUNDAI / KIA
51712-J1500
KIA
51712-2V000
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.10~08.13 | 1600 | G4FD | PSD11 LHD KDOM | RN1548V | PN0537 | RN1549 | PN0538 | |
| 01.10~12.13 | 1600 | G4FG | PSD11 LHD | RN1548V | PN0537 | DN1106RN1549 | PN0538FN0609 | |
| 01.10~01.15 | 1600 | G4FG | PSD11 RHD | RN1548V | PN0537 | DN1106RN1549 | PN0538FN0609 | |
| 09.11~07.13 | 1800 | G4NB | PSD11 LHD | RN1548V | PN0537 | RN1549DN1106 | PN0538FN0609 |
| 08.13~08.15 | 1600 | D4FB | MD | RN1548V | PN0537 | RN1549 | PN0538 | |
| 07.13~09.15 | 1600 | G4FG | MD | RN1548V | PN0537 | RN1549 | PN0538 | |
| 07.13~09.15 | 1800 | G4NB | MD | RN1548V | PN0537 | RN1549 | PN0538 | |
| 01.14~01.16 | 1800 | G4NB | PSDA14 US | RN1548V | PN0537 | RN1549 | PN0538 | |
| 07.13~09.15 | 2000 | G4NA | MD | RN1548V | PN0537 | RN1549 | PN0538 |
| 09.15~07.19 | 1600 | D4FB | AD | RN1548V | PN0772 | RN1549 | PN0538 | |
| 09.15~07.19 | 1600 | D4FB | RPF216 | RN1548V | PN0772 | RN1549DN1106 | FN0609PN0538 | |
| 09.15~07.19 | 1600 | G4FG | PF216 LHD | RN1548V | PN0772 | RN1549 | PN0538 | |
| 09.15~07.19 | 1600 | G4FG | PF216 RHD | RN1548V | PN0772 | DN1106RN1549 | FN0609PN0538 | |
| 09.15~07.19 | 1600 | L4FA | PF216 | RN1548V | PN0772 | DN1106RN1549 | FN0609PN0538 | |
| 09.15~07.19 | 2000 | G4NA | AD | RN1548V | PN0772 | RN1549 | PN0538 | |
| 02.16~02.19 | 2000 | G4NH | PF316 US | RN1548V | PN0772 | DN1106 | FN0609 |
| 08.18~08.20 | 1600 | G4FG | PF219 RHD | RN1548V | PN0772 | RN1549 | FN0609PN0538 | |
| 08.18~08.20 | 2000 | G4NA | PF219 RHD | RN1548V | PN0772 | RN1549 | FN0609PN0538 | |
| 08.18~08.20 | 2000 | G4NH | AD | RN1548V | PN0772 | RN1549 | FN0609PN0538 |
| 08.16~05.21 | 1600 | G4FG | M017 RU | RN1548VRN1348V | PN0373 | RN1549RN2086 | PN0436 | |
| 03.20~10.21 | 2000 | G4NA | M017 RU | RN1548VRN1348V | PN0373 | RN2086RN1549 | PN0436 |
| 06.23~ | 1500 | G4FL | P1U24 SDN CHINA | RN1548V | RN2272 | PN6150 | ||
| 09.15~ | 1600 | G4FG | AD LHD PR | RN1548V | PN0772 | RN1549DN1106 | FN0609PN0538 | |
| 08.18~08.20 | 1600 | G4FG | PF219 LHD | RN1548V | PN0772 | RN1549 | PN0538 | |
| 01.16~02.19 | 2000 | G4NH | PF316 US | RN1548V | PN0772 | DN1106 | FN0609 | |
| 02.19~ | 2000 | G4NH | PF319 MEX | RN1548V | PN0772 | RN1549 | PN0538 |
| 09.11~03.15 | 1600 | G4FG | D351 5DR RHD | RN1548V | PN0537 | RN1549 | PN0538 | |
| 09.11~03.15 | 1800 | G4NB | PA512 RHD | RN1548V | PN0537 | RN1549 | PN0538 |
| 09.20~ | 1000 | G3LE | PJ921 RHD | RN1548V | PN0373 | RN1549 | PN0436 | |
| 06.17~ | 1600 | D4FB | PJ918 LHD | RN1548V | PN0373 | RN1947 | PN0436 | |
| 09.20~ | 2000 | G4NS | PJ921 LHD | RN1548V | PN0373 | RN1549 | PN0436 |
| 01.12~01.15 | 1600 | G4FD | TC61D | RN1548V | PN0537 | RN1549 | PN0538 | |
| 01.15~02.18 | 1600 | G4FD | TC6AD | RN1548V | PN0537 | RN1549 | PN0538 | |
| 03.11~01.15 | 1600 | G4FD | TE61D | RN1548V | PN0537PN11001 | RN1549 | PN0538 | |
| 01.12~01.15 | 1600 | G4FG | TC61C | RN1548V | PN0537PN11001 | RN1549 | PN0538 |
| 10.18~06.22 | 1000 | G3LC | PSP19 RHD | RN1548V | PN0958 | FN0609 | ||
| 06.22~ | 1000 | G3LC | PSP22 RHD | RN1548V | PN0958 | FN0609 | ||
| 04.19~ | 1600 | G4FG | PSN19 LHD CHL | RN1548V | PN0958 | RN1549 | PN0538 | |
| 04.19~ | 1600 | G4FG | PSN19 RHD | RN1548V | PN0958 | RN1549 | PN0538 | |
| 04.19~ | 1600 | G4FM | PSN19 RHD | RN1548V | PN0958 | RN1549 | PN0538 | |
| 09.19~ | 1600 | G4FM | QXI | RN1548V | PN0958 | RN1549 | PN0538 |
