NiBK Brakes:: Application Cross Reference and Image for NiBK : BRAKE SHOE : FN0716

BRAKE SHOE » FN0716

Specification

Radius

83

Width

26

Thickness

4.6

Pcs In Set

4

Cross Reference

FMSI

S982-1661

HYUNDAI

58305-2TA00

HYUNDAI

58305-3LA10

HYUNDAI

58305-3QA00

HYUNDAI / KIA

583053QA01

KIA

58305-2TA00

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » Azera

01.11~07.14	3000	G6DE	FH41	RN1547V RN1644V	PN0537 PN0536	RN1476 RN1601	PN0778 PN0591	FN0716
09.11~06.16	3300	G6DH	HG	RN1644V RN1547V	PN0536 PN11001	RN1476 RN1601	PN0591 PN0778	FN0716

HYUNDAI » Grandeur HG

05.14~10.16	2200	D4HB	PHG15	RN1644V	PN0799	RN1476 RN1601	PN0591 PN0778	FN0716
06.14~10.16	2400	G4KE	HG		PN11001 PN0537		PN0778	FN0716
11.11~06.14	3000	G6DG	HG		PN11001 PN0537		PN0778	FN0716
06.14~10.16	3000	G6DG	HG		PN11001 PN0537		PN0778	FN0716
11.11~06.14	3000	L6DB	PHG11	RN1547V	PN0536	RN1476	PN0591	FN0716
11.11~06.14	3300	G6DH	HG		PN11001 PN0537		PN0778	FN0716
06.14~10.16	3300	G6DH	HG		PN11001 PN0537		PN0778	FN0716

HYUNDAI » Sonata

11.10~01.15

2400

G4KK

PGFE11 GL

RN1348V

PN0536

RN1476

PN0591

FN0716

HYUNDAI » Sonata 10

09.09~06.14	2000	G4KH	PGFA10 US	RN1348V	PN0536	RN1476	PN0591	FN0716
07.12~04.14	2000	G4NE	YF	RN1348V	PN0536	RN1476	PN0591	FN0716
09.09~07.12	2400	G4KJ	PGFA10 US	RN1348V	PN0536	RN1476	PN0591	FN0716
09.09~03.14	2400	G4KJ	YF	RN1348V	PN0536	RN1476	PN0591	FN0716
11.10~07.12	2400	G4KK	PGFE11 US	RN1348V	PN0536	RN1476	PN0591	FN0716

KIA » K5

05.10~06.13	2000	G4KD	PTF11	RN1174V	PN0635	RN1307	PN0591	FN0716
06.13~07.15	2000	G4KH	PTF14	RN1644V	PN11001	RN1307 RN1601	PN0538 PN0591	FN0716
05.10~06.13	2000	G4NA	PTF11	RN1174V	PN11001 PN0635	RN1601 RN1307	PN0538 PN0591	FN0716
02.18~12.20	2000	G4ND	PD418	RN1644V	PN11001 PN0578	RN1601	PN0538	FN0716
05.10~06.13	2000	L4KA	PTF11	RN1174V	PN0635	RN1601 RN1307	PN0591 PN0538	FN0716
06.13~07.15	2000	L4NA	PTF14	RN1174V	PN0635	RN1307 RN1601	PN0591 PN0538	FN0716
05.10~06.13	2400	G4KJ	PTF11	RN1348V	PN0536	RN1476	PN0591	FN0716

KIA » Optima

03.12~	2000	G4KD	GN	RN1644V	PN0739 PN11001	RN1476	PN0591	FN0716
03.10~03.13	2000	G4KD	PTF11 LHD	RN1174V	PN0635	RN1307	PN0591	FN0716
01.10~01.13	2000	G4KD	PTF11 RHD	RN1174V RN1644V	PN11001 PN0635	RN1307 RN1476	PN0591	FN0716
08.13~02.16	2000	G4NA	GM41	RN1174V	PN0635	RN1307	PN0591	FN0716
03.10~09.13	2000	G4NA	PTF11 LHD	RN1644V	PN11001	RN1476	PN0591	FN0716
08.13~02.16	2000	G4ND	GN	RN1644V	PN11001	RN1601	PN0538	FN0716
03.10~03.14	2000	G4NE	PTFE11	RN1348V	PN0536	RN1476	PN0591	FN0716
03.10~09.13	2400	G4KE	PTF11 LHD	RN1174V	PN0635	RN1307	PN0591	FN0716
03.10~09.13	2400	G4KE	PTF11 RHD	RN1644V	PN11001	RN1476	PN0591	FN0716
04.13~03.16	2400	G4KE	PTF14 LHD	RN1174V	PN0635	RN1307	PN0591	FN0716
04.13~03.16	2400	G4KE	PTF14 RHD	RN1644V	PN11001	RN1476	PN0591	FN0716

KIA » Optima (USA)

03.10~09.13	2400	G4KJ	PTF11	RN1348V	PN0536	RN1476	PN0591	FN0716
12.11~09.13	2400	G4KJ	TFA12	RN1348V	PN0536	RN1476	PN0591	FN0716
04.13~02.16	2400	G4KJ	TFA14	RN1348V	PN0536	RN1476	PN0591	FN0716
04.13~02.16	2400	G4KK	PTFE14	RN1348V	PN0536	RN1476	PN0591	FN0716
03.10~09.13	2400	G4KK	TF	RN1348V	PN0536	RN1476	PN0591	FN0716
