ROTOR DISC » RN1174V

RN1174V

Specification

Type
Vented
Disc Thickness (Max)
26
Num. of holes
5
Height
47.4
Centering Diameter
69
Pitch Circle Ø
114.3
Front/Rear
Front
Outter Ø
280
Drum Ø:
141.6
Disc Thickness (Min)
24
Structure Material
G3000

Cross Reference

HYUNDAI
51712-2C000
HYUNDAI
51712-2E300
HYUNDAI
51712-3K010
HYUNDAI
51712-3K050
KIA
51712-1D000
KIA
51712-1D100
KIA
51712-1F000
KIA
51712-2G000
KIA
51712-3K000
KIA
51712-3K050
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   Coupe

01.04~01.08 2000 G4GC HN61 RN1174V PN0377 PN2130
03.02~06.07 2700 G6BA HN61 RN1174V PN0377 PN2130

HYUNDAI   »   i30

11.09~12.11 1400 D4FC CW RN1174V PN0373 RN1307 PN0436
03.07~12.11 1400 G4FA FD RN1174V PN0373 RN1307 PN0436
03.07~12.11 1600 D4FB FD RN1174V PN0373 RN1307 PN0436
03.07~12.11 2000 D4EA FD RN1174V PN0373 RN1307 PN0436
03.07~12.11 2000 G4GC CW RN1174V PN0373 RN1307 PN0436

HYUNDAI   »   i45

08.10~08.12 2000 G4KD EC41 RN1174V PN0704 RN1307 PN0436 FN11008
08.12~ 2000 G4NA EC41 SG RHD RN1174V PN0704 RN1307 PN0436 FN11008
08.10~08.12 2400 G4KE EC41 RN1174V PN0704 RN1307 PN0436 FN11008

HYUNDAI   »   Sonata 04

09.04~12.07 2000 G4KA NF RN1174VRN1348V PN0377 RN1476RN1386 PN0539 FN11004
09.06~12.07 2000 L4KA NF04 LHD RN1174V PN0377 RN1386 PN0539 FN11004
09.04~12.07 2400 G4KC NF RN1174V PN0377 RN1386 PN0539 FN11004
09.04~12.07 2400 G4KC NFA US RN1174V PN0377 RN1386 PN0539

HYUNDAI   »   Sonata 08

12.07~10.10 2000 G4KD NF08 LHD RN1174V PN0377 RN1386 PN0591 FN11004
12.07~10.10 2000 G4KD NF08 RHD RN1174V PN0377 RN1386 PN0539PN0591 FN11004
12.07~01.13 2000 L4KA PNF08 LHD TAXI RN1174V PN0377 RN1386 PN0591 FN11004
12.07~10.10 2400 G4KC NF RN1174V PN0377 RN1386 PN0591 FN11004
12.07~10.10 2400 G4KE ET41 LHD RN1174V PN0377 RN1386 PN0591 FN11004

HYUNDAI   »   Sonata 10

09.09~07.12 2000 G4KD PGF10 KDOM RN1174V PN0704 RN1307 PN0436 FN11008
09.09~04.14 2000 G4KD YF RN1174V PN0704PN0052 RN1307 PN0436 FN11008
09.09~04.14 2000 G4NA GF RN1174V PN0704 RN1307 PN0436 FN11008
09.09~04.14 2000 L4KA GF RN1174V PN0704 RN1307 PN0436 FN11008
09.09~04.14 2000 L4NA GF RN1174V PN0704 RN1307 PN0436 FN11008
08.10~08.14 2400 G4KE PGF10 LHD EU RN1174V PN0704 RN1307 PN0436 FN11008
08.10~10.12 2400 G4KE PGF10 LHD GEN RN1174V PN0704 RN1307 PN0436 FN11008

HYUNDAI   »   Sonata 14

04.14~03.17 2000 G4NA KEURPC114 RHD RN1174V PN0704 RN1307 PN0436 FN11008
04.14~03.17 2000 G4NA PC114 LHD RN1174V PN0704 RN1307 PN0436 FN11008
04.14~03.17 2000 L4NA PC114 DOM RN1174V PN0704 RN1307 PN0436 FN11008
04.14~03.17 2400 G4KE PC114 LHD RN1174VRN1644V PN0052PN0704 RN1601RN1307 PN0436PN0538 FN11008
04.14~03.17 2400 G4KJ LF RN1174V PN0052PN0704 RN1307RN1601 PN0538PN0436 FN11008

HYUNDAI   »   Sonata 17

03.17~01.20 2000 G4NA KEURPC117 RN1174V PN0704 RN1307 PN0436 FN11008
03.17~09.17 2400 G4KE PC117 LHD RN1174VRN1653V PN0704PN0578 RN1307RN1476RN1601 PN0436PN0538 FN11008

HYUNDAI   »   Tucson 04

10.06~01.08 2000 D4EA JM04 LHD RN1348VRN1174V PN0377 RN1176 PN0591PN0539 FN0644
10.06~12.09 2000 D4EA JM04 RHD RN1174V PN0377 RN1176 PN0539 FN0644
04.04~10.06 2000 D4EA PA04 RN1174V PN0377 RN1176 PN0539 FN0644
07.04~10.06 2000 D4EA PA04 LHD DOM RN1174V PN0377 RN1176 PN0539 FN0644
10.06~12.09 2000 G4GC JM04 RN1174V PN0377 RN1176 PN0539
10.06~01.08 2000 G4GC JM04 LHD EU RN1348VRN1174V PN0377 RN1386RN1176 PN0539PN0591 FN0644FN11004
04.04~10.06 2000 G4GC PA04 RN1174V PN0377 RN1386RN1176 PN0539 FN11004FN0644
04.04~10.06 2000 G4GC PA04 RUS RN1174V PN0377 RN1176 PN0539 FN0644
04.04~10.06 2000 G4GC PA04 US RN1174V PN0377 RN1386RN1176 PN0539 FN0644FN11004
10.06~12.09 2700 G6BA JM04 RN1174V PN0377 RN1176 PN0539
04.04~10.06 2700 G6BA PA04 RN1174V PN0377 RN1176 PN0539 FN0644

HYUNDAI   »   Tucson 10

11.09~08.13 2000 G4KD TM10 RHD RN1348VRN1174V PN0704PN0052 RN1307 PN0436 FN11006

KIA   »   Carens

06.10~12.12 1600 D4FB UN RN1174VRN1412V PN0052 PN0426 FN0731
08.09~12.12 1600 G4FC UN RN1412VRN1174V PN0052 PN0426 FN0731
10.06~08.09 2000 D4EA FG RN1174V PN0052 PN0426 FN0731
01.06~11.06 2000 G4KA BK RN1174V PN0052 PN0426 FN0731
10.06~12.12 2000 G4KA FG LHD RN1174V PN0052 PN0426 FN0731
10.06~08.09 2000 G4KA FG RHD RN1174V PN0052 PN0426 FN0731

KIA   »   K5

05.10~06.13 2000 G4KD PTF11 RN1174V PN0635 RN1307 PN0591 FN0716
05.10~06.13 2000 G4NA PTF11 RN1174V PN11001PN0635 RN1601RN1307 PN0538PN0591 FN0716
07.15~02.18 2000 G4ND PD416 KDOM RN1174V PN0704 RN1307 PN0436 FN11008
05.10~06.13 2000 L4KA PTF11 RN1174V PN0635 RN1307RN1601 PN0591PN0538 FN0716
07.15~02.18 2000 L4NA PD416 RN1174V PN0704 RN1307 PN0436 FN11008
02.18~01.20 2000 L4NA PD418 RN1174V PN0704 RN1307 PN0436 FN11008
06.13~07.15 2000 L4NA PTF14 RN1174V PN0635 RN1601RN1307 PN0591PN0538 FN0716

KIA   »   Lotze

10.05~11.10 2000 G4KA GE RN1174V PN0377 RN1386 PN0539 FN11004
06.09~01.11 2000 G4KD GG RN1174V PN0377 RN1386 PN0539 FN11004
06.09~01.11 2000 L4KA GH RN1174V PN0377 RN1386 PN0539 FN11004

KIA   »   Optima

03.10~03.13 2000 G4KD PTF11 LHD RN1174V PN0635 RN1307 PN0591 FN0716
01.10~01.13 2000 G4KD PTF11 RHD RN1174VRN1644V PN11001PN0635 RN1307RN1476 PN0591 FN0716
08.13~02.16 2000 G4NA GM41 RN1174V PN0635 RN1307 PN0591 FN0716
10.15~02.18 2000 G4NA PD416 LHD RN1174V PN0704 RN1307 PN0436 FN11008
10.15~02.18 2400 G4KE PD416 SDN LHD RN1174V PN0704 RN1307 PN0436 FN11008
03.10~09.13 2400 G4KE PTF11 LHD RN1174V PN0635 RN1307 PN0591 FN0716
04.13~03.16 2400 G4KE PTF14 LHD RN1174V PN0635 RN1307 PN0591 FN0716

KIA   »   Optima (USA)

01.05~03.08 2700 G6EA DD RN1174V PN0377 RN1386 PN0539 FN11004

KIA   »   Optima/Magentis

09.06~08.08 2000 D4EA DD RN1174V PN0377 RN1386 PN0539
05.08~05.10 2000 D4EA DD RN1174V PN0377 RN1386 PN0539
04.06~06.09 2000 D4EA MG RN1174V PN0377 RN1386 PN0539
06.09~01.11 2000 D4EA MG RN1174V PN0377 RN1386 PN0539
09.06~08.08 2000 G4KA DD RN1174V PN0377 RN1386 PN0539 FN11004
05.08~05.10 2000 G4KA DD RN1174V PN0377 RN1386 PN0539 FN11004
03.05~03.08 2000 G4KA GE22 RN1174V PN0377 RN1386 PN0539 FN11004
05.08~01.11 2000 G4KD PMG09 LHD RN1174V PN0377 RN1386 PN0539 FN11004
05.08~01.11 2000 G4KD PMG09 RHD RN1174V PN0377 RN1386 PN0539 FN11004
04.06~06.09 2400 G4KC GE22 RN1174V PN0377 RN1386 PN0539 FN11004
10.05~09.06 2700 G6EA DD RN1174V PN0377 RN1386 PN0539 FN11004
04.06~06.09 2700 G6EA MG RN1174V PN0377 RN1386 PN0539 FN11004
06.09~01.11 2700 G6EA MG RN1174V PN0377 RN1386 PN0539 FN11004

KIA   »   Rondo

04.08~12.12 2000 G4KA HG RHD AUS RN1174V PN0052 PN0426 FN0731
06.06~01.12 2400 G4KE UN06 RN1174V PN0052 PN0426 FN0731
06.06~01.12 2700 G6EA UN06 RN1174V PN0052 PN0426 FN0731

KIA   »   Sportage

03.06~08.10 2000 D4EA FQ RN1174V PN0377 RN1176 PN0539 FN0644
09.06~07.10 2000 D4EA FQ RHD RN1174V PN0377 RN1176 PN0539 FN0644
08.10~05.11 2000 D4HA PSL10 LHD KDOM RN1348VRN1174V PN0052PN0704 RN1307 PN0436 FN11008FN11009
09.06~07.10 2000 G4GC FQ LHD RN1174V PN0377 RN1176 PN0539 FN0644
09.06~07.10 2000 G4GC FQ RHD RN1174VRN1412V PN0377 DN1510RN1386RN1176 PN0539FN0820 FN11004FN0644
03.06~04.08 2000 G4GC K1F RN1412VRN1174V PN0377 RN1176DN1510 FN0820PN0539 FN0644FN11004
08.10~04.14 2000 G4KD PSL10 RHD RN1348VRN1174V PN0704PN0052 RN1176RN1307 PN0436 FN11009FN11008
08.10~10.15 2000 G4KD SL10 LHD RN1174VRN1348V PN0704PN0052 RN1307RN1176 PN0436 FN11009FN11008
12.04~09.08 2700 G6BA FQ RN1174V PN0377 RN1176 PN0539 FN0644
03.06~04.08 2700 G6BA FQ RN1174V PN0377 RN1176 PN0539 FN0644
