ROTOR DISC » RN2086

RN2086

Specification

Type
Solid
Outter Ø
262
Num. of holes
5
Disc Thickness (Max)
10
Disc Thickness (Min)
8.4
Height
28.7
Centering Diameter
76
Pitch Circle Ø
114.3
Drum Ø:
155
Structure Material
G3000

Cross Reference

HYUNDAI
58411-C9500
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   Creta

08.16~05.21 1600 G4FG M017 RU RN1548VRN1348V PN0373 RN1549RN2086 PN0436
08.16~05.21 2000 G4NA M017 RU RN1348V PN0373 RN1549RN2086 PN0436
03.20~10.21 2000 G4NA M017 RU RN1548VRN1348V PN0373 RN1549RN2086 PN0436
