BRAKE PADS » PN8485
Specification
Length-1
141.8
Width-1
56.5
Thickness-1
16.8
Pcs In Set
4
Brake System
Akebono
Cross Reference
AKEBONO
A-663WK
AKEBONO
AN-663
AKEBONO
AN-663WK
BENDIX AUS
DB1481
FMSI
D914
FMSI
D914-7795
FMSI
D943-7844
FMSI
D958
FMSI
D958-7795
HITACHI
NDP369C
HONDA
06450-S9A-A00
HONDA
06450-SCV-A02
HONDA
06450S9AA01
HONDA
06450S9AE50
HONDA
06450S9AE51
HONDA
45022-S9A-A00
HONDA
45022-S9A-A01
HONDA
45022-S9A-A02
HONDA
45022-S9A-E00
HONDA
45022-S9A-E50
HONDA
45022-S9A-E60
HONDA
45022-S9V-A01
HONDA
45022-SCV-A00
HONDA
45022-SCV-A01
HONDA
45022-SDA-A00
HONDA
45022-SDA-A10
HONDA
45022-SDA-E50
HONDA
45022-SDC-A00
HONDA
45022-SDC-A10
HONDA
45022-SDR-A00
HONDA
45022-T2F-A00
HONDA
45022-T2F-A01
HONDA
45022-TA5-A00
HONDA
45022-TBA-A00
HONDA
45022-TEA-T00
HONDA
45022-TR7-A01
HONDA
45022-TX6-A01
HONDA
45022SDA305
HONDA
45022SDAA51
HONDA
45022TA0A50
HONDA
45022TA5X00
HONDA
45022TR7A02
HONDA
45022TX6A00
HONDA
5022-S9V-A02
HONDA
H4502-S9A-901
KASHIYAMA
D5128
KASHIYAMA
D5128M02
KASHIYAMA
D5128MH
NISSAN
AY040-HN023
TOYOTA
V9118-H036
WVA
23856
WVA
23868
WVA
23869
WVA
23870
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.02~12.08 | 2000 | K20A7 | CM4 GR | RN1405VRN1218V | PN8465PN8485PN8125 | RN1203 | PN8109PN8398 | |
| 06.06~12.08 | 2000 | K20Z2 | EURO | RN1218VRN1204V | PN8125PN8485 | RN1203 | PN8398PN8109 | |
| 02.03~11.05 | 2400 | K24A | CM5 LHD | RN1218V | PN8485 | RN1203 | PN8398 | |
| 11.05~12.08 | 2400 | K24A | CM5 LHD | RN1218V | PN8485PN8465 | RN1203 | PN8398 | |
| 01.02~11.05 | 2400 | K24A8 | CM5 US | RN1218V | PN8485 | DN1393RN1203 | PN8398FN5524 | |
| 11.05~12.08 | 2400 | K24A8 | CM5 US | RN1218V | PN8485 | RN1203DN1393 | FN5524PN8398 | |
| 09.15~09.17 | 2400 | K24W | CR2 US | RN1418VRN1663VRN1218V | PN28005PN0647PN8485 | RN1425 | PN8864 | FN0663 |
| 09.12~09.15 | 2400 | K24W | CR2 US KA LX | RN1218V | PN8485 | RN1425 | PN8864 | FN0663 |
| 08.07~08.10 | 2400 | K24Z3 | CP2 US | RN1413VRN1218V | PN8465PN8485 | RN1409 | PN8864 | |
| 08.10~09.12 | 2400 | K24Z3 | CP2 US | RN1218V | PN8485 | RN1409 | PN8864 |
| 01.02~11.05 | 2400 | K24A4 | CM7 US | RN1218V | PN8485 | RN1203 | PN8398 | |
| 08.10~08.12 | 2400 | K24Z3 | CS1 | RN1218V | PN8485 | RN1409 | PN8864 |
| 05.16~ | 1500 | L15B | FC1 JPN | RN1405VRN1218V | PN8485 | RN2157 | PN8813 | |
| 05.16~08.19 | 1500 | L15B | FC1 RHD | RN1405VRN1218V | PN8485 | RN2157 | PN8813 | |
| 08.19~03.21 | 1500 | L15B | FC1 RHD | RN1405V | PN8485 | RN2157 | PN8813 | |
| 03.21~ | 1500 | L15BG | FE1 | RN1405V | PN8485 | RN2157 | PN8813 | |
| 05.16~03.21 | 1500 | L15BY | FK4 RHD | RN1405V | PN8485 | RN2157 | PN8813 | |
| 01.17~03.21 | 1500 | L15C | FK7 JPN | RN1405V | PN8485 | RN2157 | PN8813 | |
| 03.16~07.19 | 1500 | L15C | FK7 US | RN1218V | PN8485 | RN2157 | PN8813 | |
| 03.21~ | 1500 | L15C | FL1 | PN8863PN8485 | PN8813PN8822 | |||
| 01.18~ | 1600 | N16A1 | FK9 | RN1218V | PN8485 | RN2157RN2283 | PN8813 | |
| 05.16~03.21 | 1600 | R16B | FC5 | RN1405V | PN8485 | RN2157 | PN8813 | |
| 09.15~03.21 | 1600 | R16B1 | FC5 LHD | RN1405V | PN8485 | RN2157 | PN8813 | |
| 09.15~03.21 | 1600 | R16B1 | FC5 LHD | RN1405V | PN8485 | RN2157 | PN8813 | |
| 05.16~08.18 | 1800 | R18Z1 | FC6 | RN1218V | PN8485 | PN8813 | ||
| 08.18~03.21 | 1800 | R18Z1 | FC6 LHD SDN VT | RN1405V | PN8485 | RN2157 | PN8813 | |
| 08.18~03.21 | 1800 | R18Z1 | FC6 RHD SDN | RN1405V | PN8485 | RN2157 | PN8813 | |
| 01.17~03.21 | 1800 | R18Z1 | FK5 | RN1405V | PN8485 | RN2157 | PN8813 | |
| 09.15~09.18 | 2000 | K20C2 | FC2 GL | RN1218V | PN8485 | RN2157 | PN8813 |
| 09.15~09.18 | 1500 | L15B | FC1 | RN1218V | PN8485 | RN2157 | PN8813 | |
| 09.18~06.21 | 1500 | L15B | FC1 | RN1218V | PN8485 | RN2157 | PN8813 | |
| 01.12~01.14 | 1800 | R18A | FB2 | RN1468VRN1218V | PN8484PN8485 | DN1388RN1362 | PN8398FN28002 | |
| 01.14~09.15 | 1800 | R18A | FB2 | RN1218V | PN8485 | DN1388RN1362 | FN28002PN8398 | |
| 09.15~09.18 | 2000 | K20C2 | FC2 US | RN1218V | PN8485 | RN2157 | PN8813 | |
| 09.18~06.21 | 2000 | K20C2 | FC2 US | RN1218V | PN8485 | RN2157 | PN8813 | |
| 01.12~01.14 | 2400 | K24Z7 | FB6 | RN1177V | PN8485 | RN1362 | PN8398 |
| 08.01~09.04 | 2000 | K20A | RD4 LHD PH | RN1218V | PN8485 | RN1460 | PN8397 | FN0570 |
| 09.01~08.04 | 2000 | K20A | RD5 JPN | RN2054VRN1177VRN1218V | PN8485PN8484 | RN1460 | PN8807 | FN0570 |
| 11.01~11.04 | 2000 | K20A | RD5 RHD | RN1177VRN2054V | PN8484PN8485 | RN1460 | PN8807PN8397 | FN8003FN0570 |
| 11.04~04.07 | 2000 | K20A | RD5 RHD | RN2054VRN1177V | PN8484PN8485 | RN1460RN1259 | PN8397PN8807 | FN0570FN8003 |
| 01.04~08.09 | 2000 | K20A4 | RD8 | RN1177VRN1218V | PN8485 | RN1259RN1460 | PN8807PN8397 | FN8003FN0570 |
| 11.04~01.07 | 2200 | N22A2 | RD9 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 09.04~09.06 | 2400 | K24A | RD6 JPN | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 09.04~10.06 | 2400 | K24A | RD7 JPN | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 11.04~12.06 | 2400 | K24A1 | RD6 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 09.04~09.06 | 2400 | K24A1 | RD7 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 09.01~01.05 | 2400 | K24A1 | RD6 | RN1218V | PN8485 | RN1460 | PN8397 | FN0570 |
| 09.01~09.04 | 2400 | K24A1 | RD7 | RN1218V | PN8485 | RN1460 | PN8397 | FN0570 |
| 09.04~01.07 | 2400 | K24A1 | RD7 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 12.11~10.14 | 2400 | K24Z7 | RM3 US KA, KK | RN1415V | PN8802PN8485 | RN1259 | PN8807 | FN8003 |
| 03.07~07.09 | 2400 | K24 | EX | PN8485 | PN8397 | |||
| 03.07~07.09 | 2400 | K24 | LX | PN8485 | PN8397 | |||
| 04.03~07.05 | 2400 | K24A | YH2 JPN | RN1218V | PN8485 | RN2226 | PN8397 | FN0570 |
| 12.02~08.08 | 2400 | K24A | YH2 US | RN1218V | PN8485 | RN2226 | PN8397 | FN0570 |
| 08.08~05.11 | 2400 | K24A | YH2 US | RN1218V | PN8485 | RN2226 | PN8397 | FN0570 |
| 05.15~07.20 | 1500 | L15B | FR5 JPN | RN1218V | PN8485 | RN1460 | PN8807 | FN0570 |
| 02.15~07.20 | 1500 | L15B | FR5 RHD | RN1218V | PN8485 | RN1460 | PN8807 | FN0570 |
| 02.15~07.20 | 1500 | LEB-H1 | FR4 | RN1218V | PN8485 | RN1460 | PN8807 | FN0570 |
| 05.15~07.20 | 1800 | R18A | FR5 | RN1218V | PN8485 | RN1460 | PN8807 | FN0570 |
| 01.03~10.05 | 3500 | J35A# | YF1 | RN1413V | PN8485 | RN1414 | PN8803 | FN0690 |
| 10.05~10.08 | 3500 | J35A# | YF1 | RN1413V | PN8485 | RN1414 | PN8803 | FN0690 |
| 01.02~10.05 | 3500 | J35A# | YF1 US | RN1413V | PN8485 | RN1414 | PN8803 | FN0690 |
| 10.05~02.08 | 3500 | J35A# | YF1 US | RN1413V | PN8485 | RN1414 | PN8803 | FN0690 |
| 01.06~01.08 | 3500 | J35A9 | YF2 | RN1413V | PN8485 | RN1414 | PN8803 | FN0690 |
| 10.09~04.15 | 2000 | R20A | RK1 JPN | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
| 10.09~04.15 | 2000 | R20A | RK2 | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
| 10.09~04.15 | 2000 | R20A | RK3 | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
| 10.09~04.15 | 2000 | R20A | RK4 | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
| 10.09~04.15 | 2000 | R20A | RK5 JPN | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
| 01.13~04.15 | 2000 | R20A1 | RK1 GR | RN1218V | PN8485 | RN2156 | PN8807 | FN0570 |
