BRAKE SHOE » FN8003
Specification
Radius
99
Width
35
Thickness
4.5
Pcs In Set
4
Cross Reference
HONDA
43053-S9A-E50
HONDA
43053-S9A-E51
HONDA
43053-S9A-E52
HONDA
43053-S9A-E53
HONDA
43053-SWW-000
HONDA
43053-SWW-010
HONDA
43053-T1G-G00
HONDA
43154-S9A-E03
HONDA
43154-SFE-J01
HONDA
43154-SFE-J02
HONDA
43154-STK-A01
HONDA
43154-SWA-003
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.06~03.12 | 2300 | K23A1 | TB1 | RN1415V | PN8802 | RN1259 | PN8397 | FN8003 |
| 04.12~04.18 | 3500 | J35Z2 | TB3 | RN1663V | PN0647 | RN1259 | PN8807 | FN8003 |
| 04.12~04.18 | 3500 | J35Z2 | TB4 | RN1663V | PN0647 | RN1259 | PN8807 | FN8003 |
| 01.13~10.16 | 1600 | N16A1 | RE6 | RN1243V | PN8808 | RN1618 | PN8809 | FN8003 |
| 10.16~ | 1600 | N16A1 | RW | PN8802PN8808 | PN8809 | FN8003 | ||
| 02.15~12.18 | 1600 | N16A4 | RE6 | RN2353V | PN8802 | RN1618 | PN8809 | FN8003 |
| 12.03~04.07 | 2000 | K20A | RD5 RHD | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 01.04~08.09 | 2000 | K20A4 | RD8 | RN1177VRN1218V | PN8485 | RN1259RN1460 | PN8807PN8397 | FN8003FN0570 |
| 01.07~01.11 | 2000 | R20A | RE1 | RN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 01.06~09.09 | 2000 | R20A | RE2 | RN1415VRN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.09~08.12 | 2000 | R20A | RE2 | RN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 08.12~12.18 | 2000 | R20A | RE5 LHD | RN1243V | PN8808 | RN1618 | PN8809 | FN8003 |
| 10.11~01.19 | 2000 | R20A | RM1 JPN | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 10.11~01.19 | 2000 | R20A | RM1 RHD | RN1415V | PN8802 | RN1259 | PN8807PN8397 | FN8003 |
| 09.09~08.12 | 2000 | R20A2 | RE5 | RN1243V | PN8808 | RN1618 | PN8809 | FN8003 |
| 10.06~09.09 | 2000 | R20A2 | RE5 LHD | RN1243V | PN8808 | RN1618 | PN8809 | FN8003 |
| 10.06~09.09 | 2000 | R20A2 | RE5 RHD | RN1243V | PN8808 | RN1618 | PN8809 | FN8003 |
| 12.11~10.14 | 2000 | R20A5 | RM2 RHD | RN1415V | PN8802 | RN1259 | PN8397PN8807 | FN8003 |
| 10.14~01.19 | 2000 | R20A5 | RM2 RHD | PN8802 | RN1259 | PN8807PN8397 | FN8003 | |
| 01.10~01.11 | 2200 | N22A1 | RE6 | RN1243V | PN8808 | RN1618RN1259 | PN8809 | FN8003 |
| 11.04~01.07 | 2200 | N22A2 | RD9 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 09.09~12.12 | 2200 | N22B3 | RE6 | RN1243V | PN8808 | RN1618 | PN8809 | FN8003 |
| 10.12~01.15 | 2200 | N22B4 | RE6 | RN2353V | PN8802 | RN1618 | PN8809 | FN8003 |
| 09.11~09.16 | 2400 | K24 | RM3 | RN1415V | PN8802 | RN1618RN1259 | PN8807 | FN8003 |
| 08.11~08.15 | 2400 | K24 | RM4 LHD | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 12.11~08.15 | 2400 | K24 | RM4 RHD | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 06.15~12.18 | 2400 | K24 | RM4 RHD | PN8802 | RN1259 | PN8807PN8397 | FN8003 | |
| 09.04~09.06 | 2400 | K24A | RD6 JPN | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 09.04~10.06 | 2400 | K24A | RD7 JPN | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 10.06~11.11 | 2400 | K24A | RE3 JPN | RN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 10.06~11.11 | 2400 | K24A | RE4 JPN | RN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 12.11~09.16 | 2400 | K24A | RM4 JPN | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 11.04~12.06 | 2400 | K24A1 | RD6 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 09.04~09.06 | 2400 | K24A1 | RD7 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 03.07~03.13 | 2400 | K24Z | RE3 | RN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.06~09.09 | 2400 | K24Z | RE4 | RN1243VRN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.09~08.12 | 2400 | K24Z | RE4 | RN1415VRN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 12.11~10.14 | 2400 | K24Z | RM3 RHD | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 12.13~10.16 | 2400 | K24Z | RM3 RHD | PN8802 | RN1259 | PN8807PN8397 | FN8003 | |
| 03.07~03.10 | 2400 | K24Z4 | RE7 LHD | RN1243V | PN8808 | RN1618 | PN8809 | FN8003 |
| 03.10~08.12 | 2400 | K24Z4 | RE7 LHD | RN1243V | PN8808 | RN1618 | PN8809 | FN8003 |
| 12.11~10.14 | 2400 | K24 | RM4 US | RN1415V | PN8802 | RN1259 | PN8807PN8397 | FN8003 |
| 10.14~10.16 | 2400 | K24 | RM4 US | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.04~01.07 | 2400 | K24A1 | RD7 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 10.06~09.09 | 2400 | K24Z | RE3 | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.09~01.12 | 2400 | K24Z | RE3 | RN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.06~09.09 | 2400 | K24Z | RE4 | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.09~12.11 | 2400 | K24Z | RE4 | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 05.04~06.12 | 2400 | K24A | RR1 | RN2091V | PN2389 | RN1383 | PN8506 | FN8003 |
| 05.04~11.13 | 2400 | K24A | RR2 | RN2091V | PN2389 | RN1383 | PN8506 | FN8003 |
| 05.04~06.12 | 3000 | J30A | RR3 | RN2091V | PN2389 | RN1383 | PN8506 | FN8003 |
| 05.04~10.13 | 3000 | J30A | RR4 | RN2091V | PN2389 | RN1383 | PN8506 | FN8003 |
| 01.07~10.13 | 3500 | J35A | RR6 | RN2091V | PN2389 | RN1383 | PN8506 | FN8003 |
| 02.16~ | 2000 | LFA | RC4 | RN1418V | PN28005 | RN1259 | PN8807 | FN8003 |
| 10.03~10.08 | 2400 | K24A | RB1 | RN1322VRN1540V | PN8465 | RN1383 | PN8506 | FN8003 |
| 10.03~10.08 | 2400 | K24A | RB2 JPN | RN1322V | PN8465 | RN1383 | PN8506 | FN8003 |
| 10.08~10.13 | 2400 | K24A | RB3 | RN1540VRN1322V | PN8465 | RN1383 | PN8506 | FN8003 |
| 10.08~10.13 | 2400 | K24A | RB4 | RN1322V | PN8465 | RN1383 | PN8506 | FN8003 |
| 10.13~ | 2400 | K24W | MRC1 | RN1418VRN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
| 10.13~ | 2400 | K24W | RC1 JPN | RN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
| 02.14~01.18 | 2400 | K24W | RC1 RHD | RN1418V | PN28005 | RN1259 | PN8807 | FN8003 |
| 11.13~ | 2400 | K24W | RC2 | RN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
| 10.08~10.13 | 2400 | K24Z | RB3 | RN1322V | PN8465 | RN1383 | PN8506 | FN8003 |
