ROTOR DISC » RN1425

Specification

Type
Solid
Outter Ø
282
Num. of holes
5
Disc Thickness (Max)
9
Height
48.8
Centering Diameter
64
Pitch Circle Ø
114.3
Front/Rear
Rear
Drum Ø:
156
Disc Thickness (Min)
8
Structure Material
G3000

Cross Reference

HONDA
42510-T2F-A00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.12~01.15 2400 K24W7 DE1 PN0647 RN1425 PN8397
01.15~09.18 2400 K24W7 DE2 PN0647 RN1425 PN8397
06.13~08.17 2000 LFA-MF8 CR6 RN2361V PN28005 RN1425 PN8864
11.16~08.17 2400 K24W CR2 LHD RN1418V PN28005 RN1425 PN8864
01.16~09.17 2400 K24W CR2 US RN1218VRN2361V PN28005PN0647PN8485 RN1425 PN8864 FN0663
09.12~09.15 2400 K24W CR2 US KA RN1218V PN8485 RN1425 PN8864 FN0663
09.12~09.15 2400 K24W CR2 US KY RN1418V PN28005 RN1425 PN8864
06.13~08.17 3500 J35Y CR3 RN1418V PN28005 RN1425 PN8864
09.12~08.17 3500 J35Y CR3 US RN1418V PN28005 RN1425 PN8864
08.12~12.17 2400 K24W CT2 RN1418V PN28005 RN1425 PN8864
08.12~12.17 3500 J35Y CT2 RN1418V PN28005PN0647 RN1425 PN8864

Exemption from liability: the catalog data is advisory and can be used for reference only
