ROTOR DISC » RN2806V

RN2806V

Specification

Type
Vented
Outter Ø
300
Num. of holes
5
Hole Ø:
12.8
Disc Thickness (Max)
25
Disc Thickness (Min)
23
Height
47.2
Centering Diameter
64.15
Pitch Circle Ø
114.3
Drum Ø:
147.2
Front/Rear
Front
Structure Material
G3000

Cross Reference

HONDA
45251-T0H-A00
HONDA
45251-T0H-A01
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HONDA   »   CR-V (USA)

12.11~10.14 2400 K24Z7 RM3 US KA, KK RN2806VRN1415V PN8485PN8802 RN1259 PN8807 FN8003
