DRUM BRAKE » DN1388

Specification

Outter Ø
250
Num. of holes
5
Hole Ø
12.6
Centering Diameter
64.1
Height
55.7
Pitch Circle Ø
114.3
Drum Ø
200
Structure Material
G3000

Cross Reference

HONDA
42610-SNA-A00
HONDA
42610-TR3-A00
HONDA
42610-TR3-A50
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.12~01.14 1800 R18Z1 FB2 LHD 19XF RN1218V PN8465 RN1362DN1388 FN28002PN8398
01.12~01.14 1800 R18A FB2 RN1218VRN1468V PN8484PN8485 DN1388RN1362 PN8398FN28002
01.14~09.15 1800 R18A FB2 RN1218V PN8485 RN1362DN1388 FN28002PN8398
09.05~02.08 1800 R18A1 FA1 RN1468V PN8484 DN1388RN1362 PN8398FN28002
02.08~01.11 1800 R18A1 FA1 RN1468V PN8484 DN1388RN1362 PN8398FN28002
09.05~12.08 1800 R18A1 FD1 LHD RN1468V PN8484 DN1388 FN28002

Exemption from liability: the catalog data is advisory and can be used for reference only
