ROTOR DISC » RN1259
Specification
Type
Solid
Disc Thickness (Max)
9
Num. of holes
5
Height
60.7
Centering Diameter
64
Pitch Circle Ø
114.3
Front/Rear
Rear
Outter Ø
304.6
Drum Ø:
183/200
Disc Thickness (Min)
7.5
Structure Material
G3000
Cross Reference
HONDA
42510-S9A-E50
HONDA
42510-SCA-E50
HONDA
42510-STK-A00
HONDA
42510-STK-A10
HONDA
42510-SWA-000
HONDA
42510-SWA-A00
HONDA
42510-SWA-A01
HONDA
42510-SWA-A02
HONDA
42510-SXS-A00
HONDA
42510-T0A-A00
HONDA
42510-T0G-A01
HONDA
42510-T0G-A02
HONDA
42510-T0G-A04
HONDA
42510-T0N-000
HONDA
42510-T0N-010
HONDA
42510-TX4-A01
HONDA
42510-TX4-A02
OEM
42510S9AE50
OEM
42510SA9E50
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.06~03.12 | 2300 | K23A1 | TB1 | RN1415V | PN8802 | RN1259 | PN8397 | FN8003 |
| 04.12~04.18 | 3500 | J35Z2 | TB3 | RN1663V | PN0647 | RN1259 | PN8807 | FN8003 |
| 04.12~04.18 | 3500 | J35Z2 | TB4 | RN1663V | PN0647 | RN1259 | PN8807 | FN8003 |
| 11.04~04.07 | 2000 | K20A | RD5 RHD | RN1177VRN2054V | PN8484PN8485 | RN1460RN1259 | PN8397PN8807 | FN0570FN8003 |
| 01.04~08.09 | 2000 | K20A4 | RD8 | RN1218VRN1177V | PN8485 | RN1259RN1460 | PN8807PN8397 | FN8003FN0570 |
| 01.07~01.11 | 2000 | R20A | RE1 | RN1415V | PN8802 | RN1259 | PN8807PN8398 | FN8003 |
| 01.06~09.09 | 2000 | R20A | RE2 | RN1415V | PN8802 | RN1259 | PN8807PN8398 | FN8003 |
| 09.09~08.12 | 2000 | R20A | RE2 | RN1415V | PN8802 | RN1259 | PN8398PN8807 | FN8003 |
| 10.11~01.19 | 2000 | R20A | RM1 JPN | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 10.11~01.19 | 2000 | R20A | RM1 RHD | RN1415VRN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 10.11~01.19 | 2000 | R20A5 | RM1 LHD PH | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 12.11~10.14 | 2000 | R20A5 | RM2 RHD | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 10.14~01.19 | 2000 | R20A5 | RM2 RHD | RN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 10.14~01.19 | 2000 | R20A5 | RM6 MEX | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 01.10~01.11 | 2200 | N22A1 | RE6 | RN1243V | PN8808 | RN1259RN1618 | PN8809 | FN8003 |
| 11.04~01.07 | 2200 | N22A2 | RD9 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 09.11~09.16 | 2400 | K24 | RM3 | RN1415V | PN8802 | RN1259RN1618 | PN8807 | FN8003 |
| 12.11~08.15 | 2400 | K24 | RM4 RHD | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.04~09.06 | 2400 | K24A | RD6 JPN | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 09.04~10.06 | 2400 | K24A | RD7 JPN | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 10.06~11.11 | 2400 | K24A | RE3 JPN | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 10.06~11.11 | 2400 | K24A | RE4 JPN | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 12.11~09.16 | 2400 | K24A | RM4 JPN | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 08.11~08.15 | 2400 | K24A | RM4 LHD | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 11.04~12.06 | 2400 | K24A1 | RD6 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 09.04~09.06 | 2400 | K24A1 | RD7 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 10.14~10.16 | 2400 | K24W | RM3 LHD KY | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 03.07~03.13 | 2400 | K24Z | RE3 | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.09~08.12 | 2400 | K24Z | RE4 | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 12.11~10.14 | 2400 | K24Z | RM3 LHD KK | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 12.11~10.14 | 2400 | K24Z | RM3 RHD KU | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 12.13~10.16 | 2400 | K24Z | RM3 RHD KU | RN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.06~09.09 | 2400 | K24Z1 | RE4 | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 06.15~12.18 | 2400 | K24Z9 | MAKRM4 RHD KU | RN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.12~01.21 | 2400 | K24Z9 | RM3 VTN | RN1415V | PN8802 | RN1259RN1618 | PN8807 | FN8003 |
| 06.15~12.18 | 2400 | K24Z9 | RM4 RHD | RN1243V | PN8802 | RN1259 | PN8807 | FN8003 |
| 12.11~10.14 | 2400 | K24 | RM4 US | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 10.14~10.16 | 2400 | K24 | RM4 US | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.04~01.07 | 2400 | K24A1 | RD7 | RN1177V | PN8485 | RN1259 | PN8807 | FN8003 |
| 10.06~09.09 | 2400 | K24Z | RE3 | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.09~01.12 | 2400 | K24Z | RE3 | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.06~09.09 | 2400 | K24Z | RE4 | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 09.09~12.11 | 2400 | K24Z | RE4 | RN1415V | PN8802 | RN1259 | PN8807 | FN8003 |
| 12.11~10.14 | 2400 | K24Z7 | RM3 US KA, KK | RN1415V | PN8802PN8485 | RN1259 | PN8807 | FN8003 |
| 02.16~ | 2000 | LFA | RC4 JPH | RN1418V | PN28005 | RN1259 | PN8807 | FN8003 |
| 10.13~ | 2400 | K24W | MRC1 | RN1218VRN1418V | PN28005 | RN1259 | PN8807 | FN8003 |
| 10.13~ | 2400 | K24W | RC1 JPN | RN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
| 10.17~10.20 | 2400 | K24W | RC1 LHD | RN1418V | PN28005 | RN1259 | PN8807 | FN8003 |
| 02.14~01.18 | 2400 | K24W | RC1 RHD | RN1418V | PN28005 | RN1259 | PN8807 | FN8003 |
| 11.13~ | 2400 | K24W | RC2 | RN1218V | PN28005 | RN1259 | PN8807 | FN8003 |
