ROTOR DISC » RN2157
Specification
Type
Solid
Outter Ø
260
Num. of holes
5
Disc Thickness (Max)
9
Disc Thickness (Min)
8
Height
39.2
Centering Diameter
64.2
Structure Material
G3000
Pitch Circle Ø
114.3
Front/Rear
Rear
Drum Ø:
140
Cross Reference
HONDA
42510-TBA-A00
HONDA
42510-TEA-T01
HONDA
42510-TET-H00
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 05.16~ | 1500 | L15B | FC1 JPN | RN1218V | PN8485 | RN2157 | PN8813 | |
| 05.16~08.19 | 1500 | L15B | FC1 RHD | RN1218V | PN8485 | RN2157 | PN8813 | |
| 08.19~03.21 | 1500 | L15B | FC1 RHD | RN1218V | PN8485 | RN2157 | PN8813 | |
| 03.21~ | 1500 | L15B# | FE1 KN RHD RS | RN1218V | PN8485 | RN2157 | PN8813 | |
| 03.21~ | 1500 | L15BG | FE1 SG KS | RN1218V | PN8485 | RN2157 | PN8813 | |
| 05.16~03.21 | 1500 | L15BY | FK4 RHD | RN1218V | PN8485 | RN2157 | PN8813 | |
| 01.17~03.21 | 1500 | L15C | FK7 JPN | RN1218V | PN8485 | RN2157 | PN8813 | |
| 03.16~07.19 | 1500 | L15C | FK7 US | RN1218V | PN8485 | RN2157 | PN8813 | |
| 01.18~ | 1600 | N16A1 | FK9 | RN1218V | PN8485 | RN2283RN2157 | PN8813 | |
| 05.16~03.21 | 1600 | R16B | FC5 | RN1218V | PN8485 | RN2157 | PN8813 | |
| 09.15~03.21 | 1600 | R16B1 | FC5 LHD | RN1218V | PN8485 | RN2157 | PN8813 | |
| 09.15~03.21 | 1600 | R16B1 | FC5 LHD | RN1218V | PN8485 | RN2157 | PN8813 | |
| 05.16~08.18 | 1800 | R18Z1 | FC6 LHD SDN PH | RN1218V | PN8485 | RN2157 | PN8813 | |
| 08.18~03.21 | 1800 | R18Z1 | FC6 LHD SDN VT | RN1218V | PN8485 | RN2157 | PN8813 | |
| 08.18~03.21 | 1800 | R18Z1 | FC6 RHD SDN | RN1218V | PN8485 | RN2157 | PN8813 | |
| 01.17~03.21 | 1800 | R18Z1 | FK5 | RN1218V | PN8485 | RN2157 | PN8813 | |
| 09.15~09.18 | 2000 | K20C2 | FC2 GL | RN1218V | PN8485 | RN2157 | PN8813 | |
| 03.21~ | 2000 | K20C2 | FL2 | RN1218V | PN8823 | RN2157 | PN8813 |
| 09.15~09.18 | 1500 | L15B | FC1 | RN1218V | PN8485 | RN2157 | PN8813 | |
| 09.18~06.21 | 1500 | L15B | FC1 | RN1218V | PN8485 | RN2157 | PN8813 | |
| 11.20~ | 1500 | L15C | FE1 | RN2227VRN1218V | PN8819PN8823 | RN2157RN2470 | PN8813 | |
| 11.20~ | 1500 | L15C | FL1 | RN1218V | PN8823 | RN2157 | PN8813 | |
| 11.20~ | 2000 | K20C | FE2 | RN1218V | PN8823 | RN2157 | PN8813 | |
| 11.20~ | 2000 | K20C | FL2 | RN1218V | PN8823 | RN2157 | PN8813 | |
| 09.15~09.18 | 2000 | K20C2 | FC2 US | RN1218V | PN8485 | RN2157 | PN8813 | |
| 09.18~06.21 | 2000 | K20C2 | FC2 US | RN1218V | PN8485 | RN2157 | PN8813 |
| 09.21~ | 1500 | L15C8 | FE1 SDN | RN1218V | PN8811 | RN2157 | PN8813 | |
| 12.22~ | 1500 | L15C8 | FL1 | RN1218V | PN8811 | RN2157 | PN8813 |
| 04.19~03.22 | 1000 | P10A5 | FS4 | RN1218V | PN8811 | RN2157 | PN8813 | |
| 09.20~03.22 | 1500 | LEB42 | FS5 | RN1218V | PN8811 | RN2157 | PN8813 |
