ROTOR DISC » RN1409
Specification
Type
Solid
Disc Thickness (Max)
9
Num. of holes
5
Height
48.7
Centering Diameter
64
Front/Rear
Rear
Pitch Circle Ø
114.3
Outter Ø
282
Drum Ø:
157
Disc Thickness (Min)
8
Structure Material
G3000
Cross Reference
HONDA
42510-SFY-000
HONDA
42510-T7A-000
HONDA
42510-T7A-010
HONDA
42510-T7J-H00
HONDA
42510-T7W-A01
HONDA
42510-T7W-A02
HONDA
42510-T8N-T00
HONDA
42510-TA0-A00
HONDA
42510-TA0-A01
HONDA
42510-TA0-A02
HONDA
42510-TC0-T00
HONDA
42510-TVA-A00
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 04.08~06.14 | 2400 | K24Z3 | CU2 | RN1413V | PN8465 | RN1409 | PN8864 | |
| 08.09~06.14 | 3500 | J35Z6 | CU4 | RN1413V | PN8465 | RN1409 | PN8864 |
| 07.17~ | 1500 | L15B# | CV1 LHD | RN1418V | PN28005 | RN1409 | PN8822 | |
| 07.17~10.20 | 1500 | L15BE | CV1 US | RN1418VRN2227V | PN28005PN8819 | RN1409 | PN8822 | |
| 09.22~ | 1500 | L15BE | CY1 | RN2541V | PN28005 | RN1409 | PN8813 | |
| 10.21~04.23 | 1500 | L15BN | CV1 KH CHINA | RN1418V | PN28005 | RN1409 | PN8828 | |
| 10.17~ | 2000 | K20C4 | CV2 | RN2227V | PN8819 | RN1409 | PN8822 | |
| 10.18~ | 2000 | LFA-H4 | CV3 | RN2227V | PN8819 | RN1409 | PN8822PN8828 | |
| 09.15~09.17 | 2000 | LFA-MF8 | CR6 | RN1418V | PN28005 | RN1409 | PN8864 | |
| 09.22~ | 2000 | LFC5 | CY2 US | RN2227V | PN8819 | RN1409 | PN8813 | |
| 02.11~03.13 | 2000 | R20A | CU1 JPN | RN1413V | PN8465 | RN1409 | PN8864 | FN0663 |
| 11.08~08.10 | 2000 | R20A3 | CP1 LHD | RN1413V | PN8465 | RN1409 | PN8864 | |
| 01.08~08.10 | 2000 | R20A3 | CP1 RHD | RN1406VRN1413V | PN8865PN8465 | RN1407RN1409 | PN8864PN8807 | |
| 08.10~09.12 | 2000 | R20A3 | CP1 RHD | RN1413VRN1406V | PN8865PN8465 | RN1409RN1407 | PN8807PN8864 | |
| 05.08~07.11 | 2000 | R20A3 | CU1 LHD | RN1408V | PN8863 | RN1409 | PN8864 | FN0663 |
| 05.08~07.11 | 2000 | R20A3 | CU1 RHD | RN1408V | PN8863 | RN1409 | PN8864 | |
| 07.11~03.13 | 2000 | R20A3 | CU1 RHD | RN1408V | PN8863 | RN1409 | PN8864 | |
| 01.08~03.13 | 2000 | R20A3 | EURO | RN1406VRN1408V | PN8865PN8863PN8465 | RN1409RN1407 | PN8864PN8807 | |
| 12.08~03.13 | 2400 | K24A | CU2 JPN | RN1413V | PN8465 | RN1409 | PN8864 | FN0663 |
| 12.08~03.13 | 2400 | K24A | CU8 | RN1406VRN1413V | PN8865PN8465 | RN1407RN1409 | PN8864PN8807 | FN0663 |
| 11.16~08.17 | 2400 | K24W# | CR2 LHD | RN1418V | PN28005 | RN1425RN1409 | PN8864 | |
| 01.08~08.10 | 2400 | K24Z | CP2 LHD | RN1413V | PN8465 | RN1409 | PN8864 | |
| 01.08~08.10 | 2400 | K24Z | CP2 RHD | RN1406VRN1413V | PN8865PN8465 | RN1407RN1409 | PN8864PN8807 | |
| 08.10~09.12 | 2400 | K24Z | CP2 RHD | RN1413V | PN8865PN8465 | RN1409 | PN8864 | |
| 05.08~03.13 | 2400 | K24Z | CU2 RHD | RN1406VRN1413V | PN8465PN8865 | RN1407RN1409 | PN8864PN8807 | FN0663 |
| 08.10~09.12 | 2400 | K24Z2 | CP2 LHD | RN1413V | PN8465 | RN1409 | PN8864 | |
| 08.07~08.10 | 2400 | K24Z3 | CP2 US | RN1218VRN1413V | PN8465PN8485 | RN1409 | PN8864 | |
| 08.10~09.12 | 2400 | K24Z3 | CP2 US | RN1218V | PN8485 | RN1409 | PN8864 | |
| 07.08~03.13 | 2400 | K24Z3 | EURO | RN1406VRN1413V | PN8465PN8865 | RN1407RN1409 | PN8397PN8864 | |
| 01.08~01.12 | 3500 | J35Z2 | CP3 LHD | RN1413V | PN8465 | RN1409 | PN8864 | |
| 01.08~09.12 | 3500 | J35Z2 | CP3 RHD ID | RN1413V | PN8465 | RN1409 | PN8864 | |
| 01.08~01.12 | 3500 | J35Z2 | CP3 RHD KU | RN1413V | PN8465 | RN1409 | PN8864 | |
| 01.08~09.12 | 3500 | J35Z2 | CP3 RHD KU SG | RN1413V | PN8465 | RN1409 | PN8864 | |
| 08.07~08.10 | 3500 | J35Z2 | CP3 USA | RN1413V | PN8465 | RN1409 | PN8864 | |
| 08.10~08.12 | 3500 | J35Z2 | CP3 USA | RN1413V | PN8465 | RN1409 | PN8864 |
| 08.10~08.12 | 2400 | K24Z3 | CS1 | RN1218V | PN8485 | RN1409 | PN8864 | |
| 01.08~12.11 | 2400 | K24Z3 | EURO | RN1413V | PN8465 | RN1409 | PN8864 | |
| 12.08~08.10 | 3500 | J35Z | CS2 | RN1413V | PN8465 | RN1409 | PN8864 | |
| 08.10~08.12 | 3500 | J35Z | CS2 | RN1413V | PN8465 | RN1409 | PN8864 |
| 07.08~06.15 | 2000 | R20A | CW1 JPN | RN1413V | PN8465 | RN1409 | PN8864 | |
| 09.09~12.10 | 2000 | R20A3 | EURO | RN1408V | PN8863 | RN1409 | PN8864 |
| 01.15~01.18 | 1500 | L15 | JHMRU1 RHD | RN1218V | PN28005 | RN1409 | PN8812 | |
| 01.18~ | 1500 | L15 | JHMRU1 RHD | RN1218V | PN28005 | RN1409 | PN8812 | |
| 11.14~09.18 | 1500 | L15 | RU1(LHD) | RN1418V | PN28005 | RN1409 | PN8812 | |
| 05.22~ | 1500 | L15# | RV3 GL | RN1218V | PN28005 | RN1409 | PN8812 | |
| 09.18~ | 1500 | L15BY | JHMRU1 LHD | RN1418V | PN28005 | RN1409 | PN8812 | |
| 01.15~01.18 | 1500 | L15Z | RU1 RHD | RN1418V | PN28005 | RN1409 | PN8812 | |
| 01.18~08.21 | 1500 | L15Z | RU1 RHD | RN1418V | PN28005 | RN1409 | PN8812 | |
| 05.22~ | 1500 | L15ZB | RV3 RHD SG | RN1218V | PN28005 | RN1409 | PN8812 | |
| 09.21~ | 1500 | LEC3 | RV5 | RN2541V | PN28005 | RN1409 | PN8812 | |
| 05.15~09.18 | 1600 | N16A | RU8 LHD KG | RN1418V | PN28005 | RN1409 | PN8812 | |
| 05.15~ | 1600 | N16A3 | RU8 RHD | RN1418V | PN28005 | RN1409 | PN8812 | |
| 08.18~ | 1800 | R18Z7 | RU5 LHD PR | RN1418V | PN28005 | RN1409 | PN8812 | |
| 11.14~09.18 | 1800 | R18Z9 | RU5 LHD KD | RN1418V | PN28005 | RN1409 | PN8812 | |
| 08.18~ | 1800 | R18Z9 | RU5 LHD KY | RN1418V | PN28005 | RN1409 | PN8812 | |
| 11.14~09.18 | 1800 | R18Z9 | RU6 LHD US | RN1418V | PN28005 | RN1409 | PN8812 | |
| 09.18~05.22 | 1800 | R18Z9 | RU6 LHD US | RN1418V | PN28005 | RN1409 | PN8812 | |
| 08.18~ | 1800 | R18ZF | RU5 | RN1418V | PN28005 | RN1409 | PN8812 | |
| 01.14~09.18 | 1800 | R18ZF | RU5 RHD | RN1418V | PN28005 | RN1409 | PN8812 | |
| 11.14~09.18 | 1800 | R18ZG | RU5 LHD US | RN1418V | PN28005 | RN1409 | PN8812 | |
| 01.14~09.18 | 1800 | R18ZG | RU5 RHD | RN1418V | PN28005 | RN1409 | PN8812 | |
| 09.18~05.22 | 1800 | R18ZG | RU5 RHD | RN1418V | PN28005 | RN1409 | PN8812 |
| 06.03~12.07 | 3000 | J30A | UC1 | RN1413V | PN8465 | RN1409 | PN8398 | |
| 12.07~09.12 | 3500 | J35A | CP3 | RN1413V | PN8465 | RN1409 | PN8864 |
| 03.13~03.21 | 1500 | L15B | RU1 | RN1218V | PN28005 | RN1409 | PN8812 | |
| 03.13~03.21 | 1500 | L15B | RU2 | RN1218V | PN28005 | RN1409 | PN8812PN8506 | |
| 11.22~ | 1500 | L15CC CH | RV3 LHD | RN1218V | PN28005 | RN1409 | PN8812 | |
| 04.21~ | 1500 | L15Z | RV3 RHD | RN1218V | PN28005 | RN1409 | PN8812 | |
| 04.21~ | 1500 | L15Z | RV4 | RN1218V | PN28005 | RN1409 | PN8812 | |
| 03.13~03.21 | 1500 | LEB-H1 | RU3 | RN1418V | PN28005 | RN1409 | PN8812 | |
| 03.13~03.21 | 1500 | LEB-H1 | RU4 | RN1418V | PN28005 | RN1409 | PN8812 | |
| 04.21~ | 1500 | LEC | RV5 | RN1418V | PN28005 | RN1409 | PN8812 | |
| 04.21~ | 1500 | LEC | RV6 JPN | RN1418V | PN28005 | RN1409 | PN8812 |
