ROTOR DISC » RN1663V

Specification

Type
Vented
Outter Ø
311
Num. of holes
5
Disc Thickness (Max)
25
Height
47
Centering Diameter
64
Pitch Circle Ø
114.3
Drum Ø:
154
Disc Thickness (Min)
23
Structure Material
G3000

Cross Reference

HONDA
45251-T2F-A80
HONDA
45251-T2F-A81
HONDA
45251-T2F-A82
HONDA
45251-T3R-A00
HONDA
45251-TX4-A00
HONDA
45251-TX4-A01
HONDA
45251-TX4-A50
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.12~01.15 2400 K24W7 DE1 RN1663V PN0647 RN1425 PN8398
01.15~09.18 2400 K24W7 DE2 RN1663V PN0647 RN1425 PN8398
04.12~04.18 3500 J35Z2 TB3 RN1663V PN0647 RN1259 PN8807 FN8003
04.12~04.18 3500 J35Z2 TB4 RN1663V PN0647 RN1259 PN8807 FN8003
08.12~12.17 3500 J35Y CT2 RN1663VRN1418V PN28005PN0647 RN1425 PN8864
09.15~12.17 3500 J35Y CT2 US RN1663V PN0647 RN1425 PN8864

Exemption from liability: the catalog data is advisory and can be used for reference only
