BRAKE SHOE » FN2386
Specification
Radius
100
Width
30
Thickness
4.5/6.3
Pcs In Set
4
Variation
Cross Reference
CITROEN
4241N2
GEELY
1014002679
GEELY
1014003351
KASHIYAMA
K-2386
OPEL
4708598
OPEL
93193429
SUZUKI
53200-62J01
SUZUKI
53200-62J02
SUZUKI
53200M75J01
TOYOTA
04495-0D010
TOYOTA
04495-0D020
TOYOTA
04495-0D080
TOYOTA
04495-0D110
TOYOTA
04495-0H010
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 06.05~09.14 | 1000 | 1.0 i 68 | 5-Hatchback | RN1214V | PN1841 | DN1561 | FN2386 | |
| 06.05~09.14 | 1000 | 1KR-FE | RN1214V | DN1561 | PN0468FN2386 | |||
| 05.14~01.22 | 1000 | 384F | B4 | RN1214V | PN1841 | DN1561 | FN2386 | |
| 05.14~01.22 | 1200 | EB2 | B4 | RN1214V | PN1841 | DN1561 | FN2386 | |
| 08.05~09.14 | 1400 | DV4TED | RN1214V | DN1561 | PN0468FN2386 |
| 09.00~03.08 | 1000 | Z10XE | RN1131 | PN9805PN9807 | DN1568DN1569DN1567 | FN2386FN0762 | ||
| 09.00~08.04 | 1200 | Z12XE | RN1131 | PN9805PN9807 | DN1568DN1569DN1567 | FN2386FN0762 |
| 05.07~12.14 | 1000 | K10B | RN1525V | PN9805 | DN1367 | FN2386 | ||
| 03.10~12.14 | 1200 | K12B | RN1525V | PN9805 | DN1367 | FN2386 |
| 06.05~09.15 | 1000 | 1.0 i 68 | 5-Hatchback | RN1214V | PN1841 | DN1561 | FN2386 | |
| 06.05~09.15 | 1000 | 1KR-FE | Hatchback | RN1214V | PN1841 | DN1561 | FN2386 | |
| 06.05~09.15 | 1400 | DV4TED | Hatchback | RN1214V | PN1841 | DN1561 | FN2386 |
| 10.08~02.11 | 1000 | K10B | A5B310 | RN1525V | PN9805 | DN1367 | FN2386 | |
| 02.11~06.12 | 1000 | K10B | XB22S LHD | RN1525V | PN9805 | DN1367 | FN2386 | |
| 10.08~07.12 | 1200 | K12B | XB32S | RN1525V | PN9805 | DN1367 | FN2386 | |
| 09.07~05.15 | 1200 | K12MN | XB72S RHD | RN1787V | PN9529 | FN2386 | ||
| 10.08~04.11 | 1300 | D13A | A5B413D | RN1525V | PN9805 | DN1367 | FN2386 |
| 02.05~01.14 | 1000 | 1KR-FE | KGB10 | RN1214V | PN1841 | DN1561 | FN2386 | |
| 06.14~ | 1000 | 1KR-FE | KGB40R | RN1214V | PN1841 | DN1561 | FN2386 | |
| 05.14~05.18 | 1200 | EB2-DT | PAB40 | RN1214V | PN1841 | DN1561 | FN2386 | |
| 08.05~01.09 | 1400 | 2WZ-TV | WNB10 | RN1214V | PN1841 | DN1561 | FN2386 |
| 09.12~ | 1300 | 1NR-FBE | NGK11 | RN2522V | PN1853 | DN1241 | FN2386 | |
| 04.16~ | 1500 | 2NR-FE | NGK15L | RN2522V | PN1853 | DN1241 | FN2386 |
| 12.10~03.20 | 1200 | 3NR-FE | NGK10R | RN1436V | PN1853 | DN1241 | FN2386 | |
| 08.11~03.20 | 1400 | 1ND-TV | NUK10R | RN1436V | PN1853 | DN1241 | FN2386 | |
| 08.11~03.20 | 1400 | 1ND-TV | NUK15R | RN1436V | PN1853 | DN1241 | FN2386 | |
| 03.13~03.20 | 1500 | 2NR-FE | NGK12R | RN1436V | PN1853 | DN1241 | FN2386 | |
| 04.16~ | 1500 | 2NR-FE | NGK15L | RN2522V | PN1853 | DN1241 | FN2386 |
| 01.99~01.06 | 1000 | 1SZ-FE | SCP10L | RN1127VRN1144V | PN1472PN1471PN0369 | RN1308DN1206DN1239 | PN1454FN2342FN2386 | FN0614 |
| 01.99~01.05 | 1000 | 1SZ-FE | SCP10R | RN1144VRN1127V | PN1471PN0369PN1472 | RN1308DN1239 | PN1454FN2350FN2386 | FN0614 |
| 05.02~11.05 | 1300 | 2SZ-FE | SCP12L | RN1144VRN1127V | PN0369PN1472 | DN1239RN1308 | FN2386PN1454 | FN0614 |
| 01.01~06.09 | 1400 | 1ND-TV | NLP10 | PN0369 | DN1206DN1239 | FN2386 |
