ROTOR DISC » RN1436V
Specification
Type
Vented
Disc Thickness (Max)
22
Num. of holes
4
Height
46.2
Centering Diameter
55
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
258
Disc Thickness (Min)
20
Drum Ø:
131
Structure Material
G3000
Hole Ø:
14.5
Cross Reference
TOYOTA
43512-0D060
TOYOTA
43512-0D120
TOYOTA
43512-0D140
TOYOTA
43512-0D150
TOYOTA
43512-0D260
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 12.10~03.20 | 1200 | 3NR-FE | NGK10R | RN1436V | PN1853 | DN1241 | FN2386 | |
| 08.11~03.20 | 1400 | 1ND-TV | NUK10R | RN1436V | PN1853 | DN1241 | FN2386 | |
| 08.11~03.20 | 1400 | 1ND-TV | NUK15R | RN1436V | PN1853 | DN1241 | FN2386 | |
| 03.13~03.20 | 1500 | 2NR-FE | NGK12R | RN1436V | PN1853 | DN1241 | FN2386 |
| 09.11~ | 1000 | 1KR-FE | KSP130 | RN1436V | PN1508 | FN2342 | ||
| 08.05~08.11 | 1000 | 1KR-FE | KSP90L | RN1309VRN1437VRN1436V | PN1508PN1839PN1518 | DN1220RN1497DN1240RN1310 | PN1519FN0622FN2403PN1840 | |
| 08.05~08.11 | 1000 | 1KR-FE | KSP90R | RN1436VRN1309VRN1437V | PN1839PN1508PN1518 | DN1220RN1310DN1240RN1497 | FN0622PN1519PN1840FN2403 | |
| 09.11~ | 1300 | 1NR-FE | KSP130 | RN1437VRN1436V | PN1508 | FN0622 | ||
| 07.11~07.14 | 1300 | 1NR-FE | NSP130R | RN1436VRN1437V | PN1518PN1839 | RN1497DN1271DN1240 | PN1840FN0622FN2389 | |
| 01.08~09.11 | 1300 | 1NRFE | NSP90 | RN1436V | PN1839PN0369 | RN1497DN1240 | FN0622 | |
| 11.05~11.08 | 1300 | 2SZ-FE | SCP90L | RN1436V | PN1839 | DN1240RN1497 | FN0622PN1840 | |
| 11.05~11.08 | 1300 | 2SZ-FE | SCP90R | RN1436V | PN1839 | DN1240RN1497 | FN0622PN1840 | |
| 11.05~07.11 | 1400 | 1ND-TV | NLP90 | RN1436V | PN1839 | DN1240RN1497 | FN0622PN1840 | |
| 09.11~ | 1400 | 1ND-TV | P13 | RN1436V | PN1508 | FN0622 |
| 07.11~ | 1000 | 1KRFE | KSP130L | RN1436V | PN1839 | DN1240RN1497 | FN0622PN1840 | |
| 07.11~03.17 | 1300 | 1NR-FE | NSP130L | RN1436V | PN1839 | DN1240RN1497 | FN0622PN1840 | |
| 07.11~03.17 | 1300 | 1NR-FE | NSP130R | RN1436V | PN1839 | RN1497 | FN0622PN1840 | |
| 07.11~12.18 | 1400 | 1ND-TV | NLP130L | RN1436V | PN1839 | RN1497DN1240 | PN1840FN0622 | |
| 03.17~06.20 | 1500 | 2NR-FKE | NSP131L | RN1436V | PN1839 | RN1497DN1240 | FN0622PN1840 | |
| 03.17~ | 1500 | 2NR-FKE | NSP131R | RN1436V | PN1839 | RN1497 | FN0622PN1840 |
