DRUM BRAKE » DN1206
Specification
Outter Ø
233
Num. of holes
4
Centering Diameter
55.1
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000
Height
51.5
Hole Ø
14.5
Cross Reference
TOYOTA
42431-12200
TOYOTA
42431-12201
TOYOTA
42431-47010
TOYOTA
42431-47011
TOYOTA
42431-52020
TOYOTA
42431-52021
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 02.00~12.05 | 1300 | 2NZ-FE | NCP30 | RN1144V | PN1472 | DN1206 | FN2342 | |
| 01.00~12.05 | 1500 | 1NZ-FE | NCP31 | RN1144V | PN1472PN1540 | DN1206 | FN2342 | |
| 06.01~03.03 | 1500 | 1NZ-FE | NCP34 | RN1144V | PN1472 | DN1206 | FN2342 |
| 08.00~08.07 | 1300 | 2NZ-FE | NZE120L | RN1458V | PN1472 | DN1206 | FN2342 | |
| 08.00~08.08 | 1300 | 2NZ-FE | NZE120R | RN1458VRN1198V | PN1472 | RN1308DN1206 | PN1454FN2342 | FN0614 |
| 10.01~08.08 | 2000 | 2C | CE120L | RN1198V | PN1472 | RN1308DN1206 | PN1454FN2342 | FN0614 |
| 08.00~09.06 | 1500 | 1NZ-FE | NZE121 | RN1458V | PN1472 | DN1206 | FN2342 | |
| 08.00~09.06 | 1500 | 1NZ-FE | NZE121G | RN1458V | PN1472 | DN1206 | FN2342 | |
| 08.00~10.06 | 1500 | 1NZ-FE | NZE124G | RN1198V | PN1472 | DN1206 | FN2342 | |
| 08.00~09.06 | 1800 | 1ZZ-FE | ZZE122G | RN1198V | PN1472 | DN1206 | FN2342 | |
| 08.00~09.06 | 1800 | 1ZZ-FE | ZZE124 | RN1198V | PN1472 | DN1206 | FN2342 | |
| 08.00~10.06 | 1800 | 1ZZ-FE | ZZE124G | RN1198V | PN1472 | DN1206 | FN2342 | |
| 08.00~04.04 | 2200 | 3C-E | CE121G | RN1198V | PN1472 | DN1206 | FN2342 |
| 01.01~09.06 | 1500 | 1NZ-FE | NZE121 | RN1458V | PN1472 | DN1206 | FN2342 | |
| 01.01~09.06 | 1500 | 1NZ-FE | NZE124 | RN1198V | PN1472 | DN1206 | FN2342 | |
| 09.02~09.06 | 1800 | 1ZZ-FE | ZZE122 | RN1198V | PN1472 | DN1206 | FN2342 | |
| 01.01~09.06 | 1800 | 1ZZ-FE | ZZE124 | RN1198V | PN1472 | DN1206 | FN2342 |
| 08.99~09.05 | 1300 | 2NZ-FE | NCP20 | RN1144V | PN1472 | DN1206 | FN2342 | |
| 08.99~10.05 | 1500 | 1NZ-FE | NCP21 | RN1144V | PN1472 | DN1206 | FN2342 |
| 01.04~07.12 | 1300 | 2NZ-FE | NNP10 | RN1482V | PN1540 | DN1206 | FN2342 | |
| 01.04~07.12 | 1500 | 1NZ-FE | NNP11 | RN1482V | PN1540 | DN1206 | FN2342 |
| 12.97~05.00 | 1500 | 1NZ-FXE | NHW10 | RN1364V | PN1322 | DN1206 | FN2342 | |
| 05.00~08.03 | 1500 | 1NZ-FXE | NHW11L | RN1198VRN1364V | PN1472 | RN1308DN1206 | FN2342PN1454 | FN0614 |
| 01.99~01.06 | 1000 | 1SZ-FE | SCP10L | RN1144VRN1127V | PN1472PN1471PN0369 | RN1308DN1206DN1239 | FN2386PN1454FN2342 | FN0614 |
| 08.99~12.02 | 1300 | 2NZ-FE | NCP10L | RN1144VRN1127V | PN1471PN1472 | DN1206RN1308 | PN1454FN2342 | |
| 08.99~12.02 | 1300 | 2NZ-FE | NCP10R | RN1144VRN1127V | PN1471PN1472 | RN1308DN1206 | PN1454FN2342 | |
| 01.01~06.09 | 1400 | 1ND-TV | NLP10 | PN0369 | DN1239DN1206 | FN2386 | ||
| 10.01~08.05 | 1400 | 1ND-TV | NLP10 | PN1472PN1471 | DN1206DN1239 | FN2342PN1454 |
| 08.99~09.05 | 1300 | 2NZ-FE | NCP20L | RN1144V | PN1472 | DN1206RN1308 | FN2342PN1454 | FN0614 |
| 03.00~09.05 | 1300 | 2NZ-FE | NCP22 | RN1144V | PN1472PN1540 | RN1308DN1206 | FN2342PN1454 | FN0614 |
| 10.01~09.05 | 1400 | 1ND-TV | NLP20 | RN1144V | PN1472 | DN1206RN1308 | PN1454FN2342 | FN0614 |
| 10.01~09.05 | 1400 | 1ND-TV | NLP22 | RN1144V | PN1472 | DN1206RN1308 | FN2342PN1454 | FN0614 |
| 08.99~12.05 | 1500 | 1NZ-FE | NCP21 | RN1144V | PN1472 | RN1308DN1206 | PN1454FN2342 | FN0614 |
