ROTOR DISC » RN1525V

RN1525V

Specification

Type
Vented
Disc Thickness (Max)
20
Num. of holes
4
Height
40
Centering Diameter
60
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
252
Drum Ø:
127
Disc Thickness (Min)
18
Structure Material
G3000

Variation

RN1525DSET[NiBK]

Cross Reference

OEM
4708241
OEM
93192978
SUZUKI
55311-61J00
SUZUKI
55311-62J01
SUZUKI
55311-62J02
SUZUKI
55311-62J10
SUZUKI
5531162J00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

OPEL   »   Agila (B)

05.07~12.14 1000 K10B RN1525V PN9805 DN1367 FN2386
03.10~12.14 1200 K12B RN1525V PN9805 DN1367 FN2386

SUZUKI   »   Splash

10.08~02.11 1000 K10B A5B310 RN1525V PN9805 DN1367 FN2386
02.11~06.12 1000 K10B XB22S LHD RN1525V PN9805 DN1367 FN2386
10.08~07.12 1200 K12B XB32S RN1525V PN9805 DN1367 FN2386
10.08~04.11 1300 D13A A5B413D RN1525V PN9805 DN1367 FN2386

SUZUKI   »   Swift III

01.03~12.07 1500 M15A ZC21S RS415-1 RHD RN1525VRN2245VRN1649V PN9529PN9805 DN1368RN1524 PN8398FN9969
01.05~09.10 1600 M16A EZC31S RN1525VRN2245VRN1649V PN9529PN9805 DN1117RN1524 FN9969PN8398FN0032
