DRUM BRAKE » DN1241

DN1241

Specification

Outter Ø
234
Num. of holes
4
Hole Ø
14.8
Centering Diameter
55
Height
54
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

TOYOTA
42431-0D140
TOYOTA
42431-0D150
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Etios

09.12~ 1300 1NR-FBE NGK11 RN2522V PN1853 DN1241 FN2386
04.16~ 1500 2NR-FE NGK15L RN2522V PN1853 DN1241 FN2386

TOYOTA   »   ETIOS CROSS

01.14~ 1400 1ND-TV NUK10R RN1436V PN1853 DN1241 FN2386

TOYOTA   »   Etios Liva

12.10~03.20 1200 3NR-FE NGK10R RN1436V PN1853 DN1241 FN2386
08.11~03.20 1400 1ND-TV NUK10R RN1436V PN1853 DN1241 FN2386
08.11~03.20 1400 1ND-TV NUK15R RN1436V PN1853 DN1241 FN2386
03.13~03.20 1500 2NR-FE NGK12R RN1436V PN1853 DN1241 FN2386
04.16~ 1500 2NR-FE NGK15L RN2522V PN1853 DN1241 FN2386
