DRUM BRAKE » DN1239

Specification

Outter Ø
233
Num. of holes
4
Hole Ø
14.8
Centering Diameter
55
Height
51.6
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

TOYOTA
42431-0D010
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.99~01.06 1000 1SZ-FE SCP10L RN1127VRN1144V PN1471PN0369PN1472 DN1206DN1239RN1308 FN2342FN2386PN1454 FN0614
01.99~01.05 1000 1SZ-FE SCP10R RN1127VRN1144V PN1471PN0369PN1472 RN1308DN1239 FN2386PN1454FN2350 FN0614
05.02~11.05 1300 2SZ-FE SCP12L RN1144VRN1127V PN0369PN1472 RN1308DN1239 PN1454FN2386 FN0614
01.01~06.09 1400 1ND-TV NLP10 PN0369 DN1206DN1239 FN2386
10.01~08.05 1400 1ND-TV NLP10 PN1471PN1472 DN1239DN1206 PN1454FN2342

Exemption from liability: the catalog data is advisory and can be used for reference only
