ROTOR DISC » RN2229

Specification

Type
Solid
Outter Ø
284
Num. of holes
5
Disc Thickness (Max)
10
Disc Thickness (Min)
8.5
Height
32
Centering Diameter
69
Pitch Circle Ø
114.3
Structure Material
G3000
Hole Ø:
12.5
Drum Ø:
155
Front/Rear
Rear

Cross Reference

HYUNDAI
58411-J9500
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.18~ 1600 D4FE RN1644VRN1653V PN0373PN0052 RN1549RN2229 PN0436
07.17~ 1600 G4FJ RN1653VRN1644V PN0052 RN1549RN2229 PN0436
06.17~ 2000 G4NH PJ918 LHD US RN1653V PN0578 RN2229 PN0436

Exemption from liability: the catalog data is advisory and can be used for reference only
