ROTOR DISC » RN1547V

Specification

Type
Vented
Outter Ø
300
Num. of holes
5
Disc Thickness (Max)
28
Height
47.3
Centering Diameter
69
Pitch Circle Ø
114.3
Front/Rear
Front
Drum Ø:
141
Disc Thickness (Min)
26.4
Structure Material
G3000

Cross Reference

HYUNDAI
51712-2L500
HYUNDAI
51712-3V000
HYUNDAI / KIA
51712-A6600
HYUNDAI / KIA
51712-F6000
KIA
51712-3R000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.11~06.14 3000 L6DB PHG11 RN1547V PN0536 RN1476 PN0591 FN0716
10.16~11.19 3000 L6DB PG817 RN1547V PN0955 RN1476 PN0538PN0956
09.11~03.15 1400 G4FA D351 RN1547VRN1562V PN0537PN11001 PN0538
09.11~03.15 1600 G4FD D351 RN1547VRN1562V PN11001PN0537 RN1549RN1563 PN0538
01.15~07.17 1600 G4FJ PA616 5DR LHD RN1547VRN1562V PN0739 RN1549 PN0538
03.11~01.15 1600 G4FJ PGS11 RHD SG RN1547V PN11001 RN1549 PN0538
01.15~01.18 1600 G4FJ PGS15 RHD SG RN1547V PN11001 RN1549 PN0538
01.09~01.16 2400 G4KJ PJG08 RN1547V PN0052 RN1476 PN0436
01.09~03.11 2700 G6EA PJG08 RN1547V PN0052 RN1476 PN0436
01.09~01.16 3500 G6DC PJG08 RN1547V PN0052 RN1476 PN0436
03.12~07.15 1600 D4FB PA212 HB ER RN1547V PN0739PN11001 RN1563 PN0538
05.15~07.18 1600 G4FG A216 RN1547V PN0739 RN1549 PN6148
01.09~01.16 2400 G4KJ VG RN1547V PN0052 RN1476 PN0436
01.09~03.11 2700 G6EA VG RN1547V PN0052 RN1476 PN0436
01.16~06.19 3000 L6DB YG RN1547V PN0955 RN1476 PN0956 FN11008
01.09~01.16 3500 G6DC PJG08 RN1547V PN0052 RN1476 PN0436
08.16~01.19 1600 G4FG SPB216 LHD RN1547VRN1412V PN0704 RN1549 PN0538

Exemption from liability: the catalog data is advisory and can be used for reference only
