ROTOR DISC » RN2353V

Specification

Type
Vented
Outter Ø
315
Num. of holes
5
Hole Ø:
12.8
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
47.2
Centering Diameter
64.1
Pitch Circle Ø
114.3
Drum Ø:
159.2
Front/Rear
Front
Structure Material
G3000

Cross Reference

HONDA
45251-T1G-G00
HONDA
45251-T1G-G01
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
02.15~12.18 1600 N16A4 RE6 RN2353V PN8802 RN1618 PN8809 FN8003
10.12~01.15 2200 N22B4 RE6 RN2353V PN8802 RN1618 PN8809 FN8003

Exemption from liability: the catalog data is advisory and can be used for reference only
