ROTOR DISC » RN2470

Specification

Type
Solid
Outter Ø
282
Num. of holes
5
Disc Thickness (Max)
9
Height
37
Centering Diameter
64.1
Pitch Circle Ø
114.3
Front/Rear
Rear
Structure Material
G3000
Disc Thickness (Min)
8

Cross Reference

HONDA
42510-T2J-H00
HONDA
42510-T2J-H01
HONDA
42510-T38-A00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.22~ 1500 L15CA DE4 RN2227V PN8819 RN2470 PN8813
01.12~11.16 2400 K24V3 CR2 CH KY RN1418V PN28005 RN2470 PN8812
06.13~08.17 3500 J35Y CR3 GL CHINA RN1418V PN28005 RN2470 PN8812
12.21~ 2000 LFB11 RC4 LHD RN1418V PN28005 RN2470 PN8812

Exemption from liability: the catalog data is advisory and can be used for reference only
