NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1540V

ROTOR DISC » RN1540V

Specification

Type

Vented

Outter Ø

282

Num. of holes

5

Disc Thickness (Max)

25

Height

47.2

Centering Diameter

64.2

Pitch Circle Ø

114.3

Front/Rear

Front

Drum Ø:

142

Disc Thickness (Min)

23

Structure Material

G3000

Cross Reference

HONDA

45251-SFE-J10

HONDA

45251-SFE-J11

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HONDA » Crossroad

02.07~08.10

1800

R18A

RT1

RN1540V RN1322V

PN8465

RN1460

PN8506

FN0570

HONDA » Odyssey

10.03~10.08	2400	K24A	RB1	RN1540V RN1322V	PN8465	RN1383	PN8506	FN8003
10.08~10.13	2400	K24A	RB3	RN1322V RN1540V	PN8465	RN1383	PN8506	FN8003
