ROTOR DISC » RN2245V
Specification
Type
Vented
Outter Ø
252
Num. of holes
4
Hole Ø:
12.7
Disc Thickness (Max)
20
Disc Thickness (Min)
18
Height
40
Centering Diameter
60
Pitch Circle Ø
100
Drum Ø:
135.2
Front/Rear
Front
Structure Material
G3000
Cross Reference
MITSUBISHI
MQ501189
SUZUKI
55311-58M00
SUZUKI
55311-58M01
SUZUKI
55311-58M50
SUZUKI
55311-63J00
SUZUKI
55311-63J01
SUZUKI
55311-71L00
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 05.07~09.10 | 1200 | K12B | ZC71S JPN | RN2245V | PN9529 | DN1368 | FN9969 | |
| 11.04~12.10 | 1300 | M13A | EZC11S RHD | RN2245V | PN9529 | DN1368 | FN9969 | |
| 01.04~04.08 | 1300 | M13A | RS413-2 | RN2245V | PN9805 | DN1117 | FN0032 | |
| 03.04~04.08 | 1300 | M13A | RS413-3 RHD | RN2245V | PN9529 | RN1524DN1368 | FN9969PN8398 | |
| 03.08~01.11 | 1300 | M13A | RS413-4 | RN2245V | PN9529 | RN1524DN1368 | FN9969PN8398 | |
| 11.04~12.10 | 1300 | M13A | ZC11S JPN | RN2245V | PN9529 | DN1368 | FN9969 | |
| 11.04~09.10 | 1300 | M13A | ZD11S | RN2245V | PN9529 | FN0032FN9969 | ||
| 01.05~12.07 | 1500 | M15A | JS2ZC21S RS415-2 RHD | RN2245V | PN9529 | DN1368 | FN9969 | |
| 01.04~03.08 | 1500 | M15A | RS415-1 LHD | RN1649VRN2245V | PN9529 | DN1368RN1524 | PN8398FN9969 | |
| 01.04~03.08 | 1500 | M15A | RS415-3 LHD | RN1649VRN2245V | PN9529 | RN1524DN1368 | FN9969FN0032PN8398 | |
| 03.08~01.11 | 1500 | M15A | RS415-4 LHD | RN2245VRN1649V | PN9529 | DN1368RN1524 | FN0032FN9969PN8398 | |
| 11.04~09.10 | 1500 | M15A | ZC21S | RN2245V | PN9529 | DN1368 | FN0032FN9969 | |
| 01.03~12.07 | 1500 | M15A | ZC21S RS415-1 LHD | RN2245V | PN9529 | DN1368 | FN9969 | |
| 01.03~12.07 | 1500 | M15A | ZC21S RS415-1 RHD | RN1649VRN1525VRN2245V | PN9805PN9529 | RN1524DN1368 | PN8398FN9969 | |
| 12.07~01.11 | 1500 | M15A | ZC21S RS415-3.4 RHD | RN2245V | PN9529 | DN1368 | FN9969 | |
| 11.04~09.10 | 1500 | M15A | ZD21S | RN2245V | PN9529 | DN1117 | FN0032 | |
| 01.05~09.10 | 1600 | M16A | EZC31S | RN2245VRN1649VRN1525V | PN9529PN9805 | DN1117RN1524 | PN8398FN0032FN9969 | |
| 01.04~01.11 | 1600 | M16A | RS416 | RN2245V | PN9805 | RN1524 | PN8398FN0032 |
| 09.10~11.16 | 1200 | K12B | ZC72S JPN | RN2245VRN29001V | PN9529 | RN1955DN1369 | FN9991PN9808 | |
| 12.12~ | 1400 | K14 | AZF414 | RN2245V | PN5562PN9529 | RN1955DN1422 | FN9991PN9808 | |
| 03.10~ | 1400 | K14B | ZC82S LHD | RN2245VRN29001V | PN5562PN9529 | RN1693DN1369RN1955 | PN9808FN9991 | |
| 03.13~02.17 | 1400 | K14B | ZC82S RHD | RN29001VRN2245V | PN5562PN9529 | DN1369RN1955RN1693 | PN9808FN9991 |
