ROTOR DISC » RN1649V

Specification

Type
Vented
Outter Ø
276
Num. of holes
5
Disc Thickness (Max)
20
Height
40
Centering Diameter
62
Pitch Circle Ø
114.3
Front/Rear
Front
Drum Ø:
146

Cross Reference

SUZUKI
55311-57K00
SUZUKI
55311-57K01
SUZUKI
55312-57K00
SUZUKI
55312-57K01
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.04~03.08 1500 M15A RS415-1 LHD RN2245VRN1649V PN9529 DN1368RN1524 PN8398FN9969
01.04~03.08 1500 M15A RS415-3 LHD RN2245VRN1649V PN9529 RN1524DN1368 FN0032PN8398FN9969
03.08~01.11 1500 M15A RS415-4 LHD RN2245VRN1649V PN9529 DN1368RN1524 PN8398FN0032FN9969
01.03~12.07 1500 M15A ZC21S RS415-1 RHD RN1649VRN1525VRN2245V PN9805PN9529 RN1524DN1368 PN8398FN9969
01.05~09.10 1600 M16A EZC31S RN2245VRN1649VRN1525V PN9529PN9805 RN1524DN1117 FN0032FN9969PN8398
09.05~09.10 1600 M16A ZC31S JPN RN1649V PN9529 RN1524 PN8398

Exemption from liability: the catalog data is advisory and can be used for reference only
