DRUM BRAKE » DN1422

DN1422

Specification

Outter Ø
242
Num. of holes
4
Hole Ø
12.6
Centering Diameter
62
Height
54.8
Pitch Circle Ø
100
Drum Ø
200
Structure Material
G3000

Cross Reference

SUZUKI
43511-58M00
SUZUKI
43511-58M00-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   Swift IV

12.12~ 1400 K14 AZF414 RN2245V PN9529PN5562 RN1955DN1422 FN9991PN9808
