PERFORMANCE ROTOR DISC » RN1524DSET
Specification
Type 2:
Drilled
Outter Ø
278
Num. of holes
5
Disc Thickness (Max)
9
Disc Thickness (Min)
8.5
Height
43.4
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
168
Variation
Cross Reference
SUZUKI
55611-80J00
SUZUKI
55611-80J01
SUZUKI
55611-80J02
SUZUKI
55611-80J10
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 03.04~04.08 | 1300 | M13A | RS413-3 RHD | RN2245V | PN9529 | RN1524DN1368 | FN9969PN8398 | |
| 03.08~01.11 | 1300 | M13A | RS413-4 | RN2245V | PN9529 | RN1524DN1368 | FN9969PN8398 | |
| 01.04~03.08 | 1500 | M15A | RS415-1 LHD | RN2245VRN1649V | PN9529 | DN1368RN1524 | PN8398FN9969 | |
| 01.04~03.08 | 1500 | M15A | RS415-3 LHD | RN1649VRN2245V | PN9529 | RN1524DN1368 | FN9969FN0032PN8398 | |
| 03.08~01.11 | 1500 | M15A | RS415-4 LHD | RN2245VRN1649V | PN9529 | DN1368RN1524 | FN9969PN8398FN0032 | |
| 01.03~12.07 | 1500 | M15A | ZC21S RS415-1 RHD | RN1525VRN2245VRN1649V | PN9805PN9529 | RN1524DN1368 | FN9969PN8398 | |
| 01.05~09.10 | 1600 | M16A | EZC31S | RN2245VRN1649VRN1525V | PN9529PN9805 | RN1524DN1117 | FN0032FN9969PN8398 | |
| 01.04~01.11 | 1600 | M16A | RS416 | RN2245V | PN9805 | RN1524 | PN8398FN0032 | |
| 09.05~09.10 | 1600 | M16A | ZC31S JPN | RN1649V | PN9529 | RN1524 | PN8398 |
| 07.06~03.16 | 1600 | M16A | GYA21S | RN1320V | PN2201 | RN1524RN1755DN1372 | FN9801PN8398 | |
| 06.06~12.15 | 1600 | M16A | GYC21S SDN | RN1320V | PN2201 | RN1755RN1524DN1372 | FN9801PN8398 | |
| 02.08~11.11 | 1600 | M16A | RW416-4,5 HB RHD | RN1320V | PN2201 | RN1524 | PN8398 | |
| 11.11~12.15 | 1600 | M16A | RW416-6 RHD | RN1320V | PN2201 | RN1524 | PN8398FN9801 | |
| 06.06~01.10 | 2000 | J20A | JS2YA4 | RN1320V | PN2201 | RN1524 | FN9801PN8398 | |
| 04.07~07.12 | 2000 | J20A | JS2YC4 SDN | RN1320V | PN2201 | RN1524DN1372 | PN8398FN9801 | |
| 07.06~05.09 | 2000 | J20A | YA41S | RN1320V | PN2201 | RN1524 | PN8398 | |
| 07.06~05.09 | 2000 | J20A | YB41S | RN1320V | PN2201 | RN1524 | PN8398 | |
| 07.09~04.14 | 2000 | J20B | JS2YA5 | RN1320V | PN2201 | RN1524 | PN8398 | |
| 07.09~04.14 | 2000 | J20B | JS2YB5 | RN1320V | PN2201 | RN1524 | PN8398 | |
| 07.09~04.14 | 2000 | J20B | JS2YC5 SDN | RN1320V | PN2201 | RN1524DN1372 | PN8398FN9801 | |
| 01.10~06.12 | 2000 | J20B | YB41S | RN1320VRN1692V | PN2201 | RN1524RN1693 | FN9801PN8398 | |
| 06.12~03.14 | 2000 | J20B | YB51S RHD | RN1320V | PN2201 | RN1524 | PN8398 |
