DRUM BRAKE » DN1372

DN1372

Specification

Outter Ø
262
Num. of holes
5
Hole Ø
12.6
Centering Diameter
62
Height
59.3
Pitch Circle Ø
114.3
Drum Ø
220
Structure Material
G3000

Cross Reference

SUZUKI
43511-80J00
SUZUKI
43511-80J00-000
SUZUKI
43511-80J01
SUZUKI
43511-80J01-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

SUZUKI   »   SX-4

05.06~ 1500 M15A YA11S RN1320V PN2201 DN1372 FN9801
05.06~10.14 1500 M15A YB11S RN1320V PN2201 DN1372 FN9801
06.07~ 1500 M15A YC11S RN1320V PN2201 DN1372 FN9801
07.06~03.16 1600 M16A GYA21S RN1320V PN2201 RN1755DN1372RN1524 FN9801PN8398
06.06~12.15 1600 M16A GYC21S SDN RN1320V PN2201 DN1372RN1755RN1524 FN9801PN8398
04.07~07.12 2000 J20A JS2YC4 SDN RN1320V PN2201 RN1524DN1372 FN9801PN8398
07.09~04.14 2000 J20B JS2YC5 SDN RN1320V PN2201 RN1524DN1372 PN8398FN9801

SUZUKI   »   SX4 S-Cross

06.06~12.15 1600 M16A YA21S RN1320V PN2201 DN1372 FN9801PN8398
