ROTOR DISC » RN1755

Specification

Type
Solid
Outter Ø
278
Num. of holes
5
Disc Thickness (Max)
9
Height
43.2
Centering Diameter
62
Pitch Circle Ø
114
Front/Rear
Rear
Drum Ø:
168
Disc Thickness (Min)
8
Structure Material
G3000

Cross Reference

FIAT
71750932
FIAT
71768089
SUZUKI
55611-55L00
SUZUKI
55611-55L01
SUZUKI
55611-55L01-000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.06~09.09 1900 D19AA 189 RN1320V PN9803 DN1371RN1755 PN8398FN0634
06.06~12.15 1600 9HX YY5 RN1320V PN9803 RN1755 PN8398FN0634
07.06~03.16 1600 M16A GYA21S RN1320V PN2201 RN1524RN1755DN1372 FN9801PN8398
06.06~12.15 1600 M16A GYC21S SDN RN1320V PN2201 RN1755RN1524DN1372 FN9801PN8398
06.06~12.11 1600 M16A RW416 MAGYAR RN1320V PN9803 RN1755DN1371 FN0634PN8398
07.09~01.16 2000 D20AA GY RN1320V PN9803 RN1755 PN8398FN0634

Exemption from liability: the catalog data is advisory and can be used for reference only
