ROTOR DISC » RN2193V

Specification

Type
Vented
Outter Ø
303
Num. of holes
5
Disc Thickness (Max)
28
Disc Thickness (Min)
26.4
Height
47
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
141
Structure Material
G3000
Front/Rear
Front

Cross Reference

HYUNDAI
51712-39910
HYUNDAI
51712-3F000
HYUNDAI
51712-3L000
HYUNDAI
51712-3L010
HYUNDAI
51712-3L050
HYUNDAI
51712-3L060
HYUNDAI / KIA
51712-39900
HYUNDAI / KIA
517123F000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
02.05~12.11 3300 G6DB FC41 RN2193V PN0377 PN0539 FN11005
09.05~12.11 2700 L6EA TG RN2193V PN0377 PN0539 FN11005
01.04~11.06 3500 G6CU EH RN2193V PN0115 PN0539 FN0763
03.03~11.06 3000 G6CT K3F RN2193V PN0853 PN0539 FN0763
03.03~05.06 3500 G6CU EH RN2193V PN0115 PN0539 FN0763

Exemption from liability: the catalog data is advisory and can be used for reference only
