ROTOR DISC » RN1609

Specification

Type
solid
Outter Ø
305
Num. of holes
5
Disc Thickness (Max)
9
Height
61
Centering Diameter
64
Pitch Circle Ø
114.3
Front/Rear
Rear
Drum Ø:
190
Disc Thickness (Min)
8
Structure Material
G3000

Cross Reference

HONDA
42510-T2M-T01
HONDA
42510-T2M-T02
HONDA
42510-TP6-A00
HONDA
42510-TP6-A01
HONDA
42510-TW1-W01
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.13~03.16 2000 LFA-MF8 CR5 JPN RN1418V PN28005 RN1609 PN8807 FN0663
09.12~11.16 2000 R20Z CR1 RN1418V PN28005 RN1609 PN8397PN8807 FN0663
11.16~08.19 2000 R20Z CR1 RN1418V PN28005 RN1609 PN8807PN8397 FN0663
11.16~08.18 2400 K24W6 CR2 RHD RN1418V PN28005 RN1609 PN8807PN8397 FN0663
01.12~11.16 2400 K24WZ CR2 RN1418V PN28005 RN1609 PN8807 FN0663
06.12~08.15 2400 K24Y2 TF385 RN1415V PN8802 RN1609 PN8807 FN0663
03.10~08.15 3500 J35Z2 TF285 RN1415V PN8802 RN1609 PN8807 FN0663

Exemption from liability: the catalog data is advisory and can be used for reference only
