DRUM BRAKE » DN1240

DN1240

Specification

Outter Ø
243
Num. of holes
4
Hole Ø
14.5
Centering Diameter
55
Height
57.1
Pitch Circle Ø
100
Drum Ø
202.6
Structure Material
G3000

Cross Reference

TOYOTA
42431-0D030
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Yaris

08.05~08.11 1000 1KR-FE KSP90L RN1436VRN1309VRN1437V PN1508PN1839PN1518 DN1220RN1497DN1240RN1310 PN1840PN1519FN0622FN2403
08.05~08.11 1000 1KR-FE KSP90R RN1436VRN1309VRN1437V PN1839PN1508PN1518 RN1497DN1220RN1310DN1240 FN2403FN0622PN1519PN1840
07.11~07.14 1300 1NR-FE NSP130R RN1437VRN1436V PN1839PN1518 DN1240RN1497DN1271 PN1840FN0622FN2389
01.08~09.11 1300 1NRFE NSP90 RN1436V PN1839PN0369 RN1497DN1240 FN0622
11.05~11.08 1300 2SZ-FE SCP90L RN1436V PN1839 DN1240RN1497 FN0622PN1840
11.05~11.08 1300 2SZ-FE SCP90R RN1436V PN1839 DN1240RN1497 PN1840FN0622
11.05~07.11 1400 1ND-TV NLP90 RN1436V PN1839 DN1240RN1497 FN0622PN1840

TOYOTA   »   Yaris/Hybrid

07.11~ 1000 1KRFE KSP130L RN1436V PN1839 RN1497DN1240 FN0622PN1840
07.11~03.17 1300 1NR-FE NSP130L RN1436V PN1839 RN1497DN1240 PN1840FN0622
07.11~12.18 1400 1ND-TV NLP130L RN1436V PN1839 DN1240RN1497 FN0622PN1840
03.17~06.20 1500 2NR-FKE NSP131L RN1436V PN1839 DN1240RN1497 PN1840FN0622
