ROTOR DISC » RN1497
Specification
Type
Solid
Disc Thickness (Max)
9
Num. of holes
4
Height
25.2
Centering Diameter
54.9
Front/Rear
Rear
Outter Ø
278
Disc Thickness (Min)
7
Pitch Circle Ø
100
Drum Ø:
139
Structure Material
G3000
Cross Reference
TOYOTA
424310D060
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.05~08.11 | 1000 | 1KR-FE | KSP90L | RN1437VRN1436VRN1309V | PN1518PN1508PN1839 | RN1310DN1220RN1497DN1240 | FN0622FN2403PN1840PN1519 | |
| 08.05~08.11 | 1000 | 1KR-FE | KSP90R | RN1437VRN1436VRN1309V | PN1508PN1518PN1839 | RN1310DN1240RN1497DN1220 | PN1840FN2403FN0622PN1519 | |
| 07.11~07.14 | 1300 | 1NR-FE | NSP130R | RN1436VRN1437V | PN1518PN1839 | RN1497DN1271DN1240 | PN1840FN0622FN2389 | |
| 01.08~09.11 | 1300 | 1NRFE | NSP90 | RN1436V | PN1839PN0369 | DN1240RN1497 | FN0622 | |
| 11.05~11.08 | 1300 | 2SZ-FE | SCP90L | RN1436V | PN1839 | DN1240RN1497 | PN1840FN0622 | |
| 11.05~11.08 | 1300 | 2SZ-FE | SCP90R | RN1436V | PN1839 | DN1240RN1497 | PN1840FN0622 | |
| 11.05~07.11 | 1400 | 1ND-TV | NLP90 | RN1436V | PN1839 | DN1240RN1497 | PN1840FN0622 |
| 07.11~ | 1000 | 1KRFE | KSP130L | RN1436V | PN1839 | RN1497DN1240 | FN0622PN1840 | |
| 07.11~03.17 | 1300 | 1NR-FE | NSP130L | RN1436V | PN1839 | RN1497DN1240 | FN0622PN1840 | |
| 07.11~03.17 | 1300 | 1NR-FE | NSP130R | RN1436V | PN1839 | RN1497 | PN1840FN0622 | |
| 07.11~12.18 | 1400 | 1ND-TV | NLP130L | RN1436V | PN1839 | DN1240RN1497 | FN0622PN1840 | |
| 04.12~ | 1500 | 1NZ-FXE | NHP130L | PN1839 | RN1497 | PN1840 | ||
| 03.17~06.20 | 1500 | 2NR-FKE | NSP131L | RN1436V | PN1839 | DN1240RN1497 | PN1840FN0622 | |
| 03.17~ | 1500 | 2NR-FKE | NSP131R | RN1436V | PN1839 | RN1497 | PN1840FN0622 |
