ROTOR DISC » RN1151V
Specification
Type
Vented
Disc Thickness (Max)
26
Num. of holes
4
Height
34.2
Centering Diameter
66
Front/Rear
Front
Outter Ø
283
Pitch Circle Ø
108
Drum Ø:
133
Disc Thickness (Min)
24
Structure Material
G3000
Cross Reference
BENDIX
562129B
CITROEN
16 064 014 80
CITROEN
4246.W2
CITROEN
4249 84
CITROEN
4249.18
OPEL
3557911
PEUGEOT
16 678 574 80
PEUGEOT
4246.W8
PEUGEOT
4249.17
PEUGEOT
4249.J6
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 03.16~01.18 | 1200 | EB2DT | LCV/microBUS | RN1151V | PN0471 | RN1857H | PN0472 | |
| 03.08~ | 1600 | 1.6 HDi 75 | B9 | RN1151V | PN0471 | RN1857H | PN0472 | |
| 01.08~01.18 | 1600 | DV6ATED4 | LCV/microBUS | RN1151V | PN0471 | RN1857H | PN0472 | |
| 03.10~12.16 | 1600 | DV6AUTED4 | B9 | RN1151V | PN0471 | RN1857H | PN0472 | |
| 01.08~ | 1600 | DV6AUTED4 | B9(Long) | RN1151V | PN0471 | RN1857H | PN0472 | |
| 04.08~ | 1600 | DV6BTED4 | B9 | RN1151V | PN0471 | RN1857H | PN0472 | |
| 03.10~ | 1600 | DV6DTED | B9 | RN1151V | PN0471 | RN1857H | PN0472 | |
| 01.08~ | 1600 | DV6DTED | B9(Long) | RN1151V | PN0471 | RN1857H | PN0472 | |
| 10.15~07.19 | 1600 | DV6FD | B9(Long) | RN1151V | PN0471 | RN1857H | PN0472 | |
| 01.08~01.18 | 1600 | EP6C | LCV/microBUS | RN1151V | PN0471 | RN1857H | PN0472 | |
| 01.08~01.18 | 1600 | TU5JP | LCV/microBUS | RN1151V | PN0471 | RN1857H | PN0472 |
| 02.09~09.16 | PICASSO | RN1152VRN1151V | PN0706PN0182 | RN1747H | PN0019W | |||
| 01.15~09.16 | 1200 | EB2DT | PICASSO | RN1152VRN1151V | PN0706PN0182 | RN1747H | PN0019W | |
| 11.09~ | 1400 | 1.4 VTi 16v 95 | 5-Hatchback | RN1152VRN1151V | PN0182PN0706 | DN1586HRN1747H | FN0684PN0019W | |
| 01.02~01.09 | 1600 | 1.6 VTi 16v 120 | 5-Hatchback | RN1152VRN1151V | PN0182PN0706 | RN1747H | PN0019WFN0684 | |
| 06.09~03.13 | 1600 | DV6DTED | 5DR HB LHD | RN1152VRN1151V | PN0182PN0706 | RN1747H | PN0019W | |
| 12.12~09.16 | 1600 | DV6DTED | PICASSO LHD | RN1152VRN1151V | PN0182PN0706 | RN1747H | PN0019W |
| 01.17~ | 1200 | EB2DT | A88 | RN1151V | PN0706 | RN2278H | PN0019W | |
| 08.18~ | 1500 | DV5R# | A88 | RN1152VRN1151V | PN0182PN0706 | RN1747H | PN0019W |
| 01.16~ | 1200 | EB2DTS | B7 | RN1151V | PN0471 | RN1857H | PN0473 | |
| 11.09~12.15 | 1600 | 1.6 HDI 92 | B7 | RN1151V | PN0471 | RN1857H | PN0473 | |
| 10.04~12.10 | 1600 | 1.6 THP 16v 150 | 5-Hatchback | RN1151V | PN0187W | RN1747H | PN0019W | |
| 11.09~ | 1600 | DV6C | B7 | RN1151V | PN0471 | RN1857H | PN0473 | |
| 02.15~ | 1600 | DV6FC 120 | B7 | RN1151V | PN0471 | RN1857H | PN0473 | |
| 10.04~12.10 | 1600 | EP6 | 5-Hatchback | RN1151V | PN0187W | RN1747H | PN0019W | |
| 06.10~12.15 | 1600 | EP6 | B7 | RN1151V | PN0471 | RN1746H | PN0019W | |
| 09.08~05.11 | 1600 | EP6 | LC | RN1151V | PN0187W | RN1747H | PN0019W | |
| 10.04~05.11 | 1600 | TU5JP4 | L_ | RN1151V | PN0187W | RN1747HRN1744H | PN0069PN0019W | |
| 10.04~12.10 | 2000 | DW10TED4 | RN1151V | PN0348W | PN0069PN0019W | |||
| 10.04~12.10 | 2000 | EW10A | RN1151V | PN0348W | PN0019WPN0069 | |||
| 10.04~12.10 | 2000 | EW10J4S | LA | RN1151V | PN0348W | PN0019WPN0069 | ||
| 10.04~12.10 | 2000 | EW10J4S | LC | RN1151V | PN0348W | PN0069PN0019W |
| 09.10~08.13 | 1600 | DV6C | UA | RN1151V | PN0471 | RN1857H | PN0481 | |
| 02.07~08.13 | 1600 | DV6TED4 | RN1151V | PN0471 | ||||
| 03.08~ | 1600 | EP6DT | UD | RN1151V | PN0398W | PN0501 |
| 11.04~02.08 | 2000 | 2.0 HDi 138 | RC | RN1151V | PN0184W | RN1898 | PN0193 | |
| 11.04~02.08 | 2000 | EW10A | RC | RN1151V | PN0183W | RN1898 | PN0193 |
| 01.10~07.15 | 1600 | 1.6 THP 16v 150 | SA | RN1152VRN1151V | PN0202WPN0706PN0182 | RN1747H | FN0684PN0019W | |
| 01.10~07.15 | 1600 | 1.6 VTi 16v 120 | SA | RN1151V | PN0202WPN0706 | RN1747HDN1586H | PN0019WFN0684 |
| 05.12~07.15 | 1600 | DV6C | NX | RN1151V | PN0471 | RN1746HRN1857H | PN0473PN0019W | |
| 05.14~12.18 | 1600 | DV6FC | NX | RN1151V | PN0471 | RN1857H | PN0473 |
| 09.99~10.01 | 1600 | DV6TED4 | RN1152VRN1151V | PN0173WPN0182 | FN0600 | |||
| 07.97~10.01 | 1600 | TU5JP | RN1152VRN1004VRN1151V | PN0152PN0182PN0170PN0173W | FN0512FN0600FN0513FN0602FN0517 | |||
| 09.99~10.01 | 1800 | EW7J4 | RN1151VRN1152V | PN0187WPN0173WPN0182 | FN0600PN0019W |
| 07.19~ | 1200 | F12XHT (EB2ADTS) | 68 | RN1151VRN1748V | PN0706PN0182 | |||
| 07.19~ | 1500 | D15DT# | RN1151VRN1748V | PN0182PN0706 |
| 03.17~ | 1200 | B12XHL | D75 | RN1151V | PN0706 | RN2278H | PN0019W | |
| 03.17~ | 1200 | B12XHT | P17 | RN1151V | PN0706 | RN2278H | PN0019W |
| 01.15~12.19 | 1200 | EB2DT | CU | RN1151V | PN0706 | RN1747H | PN0019W | |
| 03.13~12.19 | 1400 | DV4C | CU | RN1151VRN1152V | PN0706PN0182 | RN1747H | PN0019W | |
| 03.13~12.19 | 1600 | EP6C | CU | RN1151V | PN0706 | RN1747H | PN0019W | |
| 02.16~ | 1600 | EP6FDT M | CU | RN1151V | PN0706 | RN1747HRN2278H | PN0019W |
| 03.07~05.15 | 1600 | 1.6 VTi 16v 120 | 2-Coupe Cabriolet | RN1151V | PN0187W | RN1747H | PN0019W | |
| 03.07~08.12 | 1600 | 1.6 VTi 16v 120 | 5-Hatchback | RN1151V | PN0187W | RN1747H | PN0019W | |
| 03.10~08.12 | 1600 | DV6ATED4 | 5-Hatchback | RN1151V | PN0187PN0187W | DN1586HRN1747H | PN0069FN0684 | |
| 03.10~08.12 | 1600 | DV6CTED | 5-Hatchback | RN1151V | PN0187WPN0187 | DN1586H | FN0684 | |
| 03.07~05.15 | 1600 | EP6 | 2-Coupe Cabriolet | RN1151V | PN0187W | RN1747H | PN0069 | |
| 03.07~08.12 | 1600 | EP6 | 5-Hatchback | RN1151V | PN0187W | RN1747H | PN0069PN0019W | |
| 01.06~01.13 | 1600 | TU5JP4 | 5-Hatchback | RN1151V | PN0187W | RN1747H | PN0019W |
| 06.19~ | 5DR HB | RN1152VRN1748VRN1151VRN1854V | PN0706PN0398WPN42006PN0182 | RN2505 | PN42007PN42008FN0619 | |||
| 06.19~ | 5DR HB | RN1152VRN1748VRN1151VRN1854V | PN0706PN0182PN42006PN0398W | RN2505 | PN42008PN42007FN0619 | |||
| 06.19~ | 1200 | EB2ADT | 5DR HB | RN1151VRN1854VRN1152VRN1748V | PN0398WPN42006PN0182PN0706 | RN2505 | FN0619PN42007PN42008 | |
| 06.19~ | 1200 | EB2F | 5DR HB | RN1152VRN1748VRN1151VRN1854V | PN0706PN0398WPN42006PN0182 | RN2505 | PN42007PN42008FN0619 | |
| 06.19~ | 1500 | DV5R# | 5DR HB | RN1151VRN1854VRN1152VRN1748V | PN0398WPN42006PN0182PN0706 | RN2505 | FN0619PN42007PN42008 | |
| 06.19~ | 1600 | DV6DTED | 5DR HB | RN1152VRN1748VRN1151VRN1854V | PN0706PN0398WPN42006PN0182 | RN2505 | PN42007PN42008FN0619 | |
| 06.19~ | 1600 | EC5F | 5DR HB | RN1151VRN1854VRN1152VRN1748V | PN0398WPN42006PN0182PN0706 | RN2505 | FN0619PN42007PN42008 |
| 01.15~05.17 | 1200 | EB2DTS | 5-Crossover | RN1151V | PN0450 | RN1857H | PN0473 | |
| 06.09~05.17 | 1600 | DV6C | 5-Crossover | RN1151V | PN0450 | RN1857H | PN0473 | |
| 05.14~05.17 | 1600 | DV6FC | 5-Crossover | RN1151V | PN0450 | RN1857H | PN0473 |
| 10.03~01.09 | 1400 | ET3J4 | RN1151VRN1152V | PN0187WPN0182 | RN1860RN1744H | PN0069PN0019W | ||
| 03.05~01.09 | 1600 | DV6TED4 | 5-Hatchback | RN1151V | PN0187W | RN1744H | PN0069PN0019W | |
| 01.01~05.05 | 1600 | TU5JP4 | 5-Hatchback | RN1151V | PN0187W | RN1860 | PN0019W | |
| 03.05~01.09 | 1600 | TU5JP4 | 5-Hatchback | RN1151V | PN0187W | RN1744H | PN0069PN0019W | |
| 01.04~12.08 | 2000 | 2.0 i 16v 138 | 2-Coupe Cabriolet | RN1151V | PN0187W | RN1744HRN1860 | PN0019WPN0069 | |
| 08.00~12.08 | 2000 | 2.0 i 16v 138 | Hatchback | RN1151V | PN0187W | RN1860RN1744H | PN0069PN0019W | |
| 05.05~12.08 | 2000 | EW10A | 2-Coupe Cabriolet | RN1151V | PN0187W | RN1744H | PN0069PN0019W | |
| 05.05~12.08 | 2000 | EW10A | ESTATE | RN1151V | PN0187W | RN1744HRN1860 | PN0019WPN0069 | |
| 03.05~11.07 | 2000 | EW10A | Hatchback | RN1151V | PN0187W | RN1747H | PN0019W | |
| 03.01~05.05 | 2000 | EW10J4 | 5DR HB | RN1151V | PN0187W | RN1860 | PN0019W |
| 06.11~06.15 | 1600 | DV6C | 5-Hatchback | RN1151V | PN0450 | RN1746H | PN0019W | |
| 06.07~06.11 | 1600 | DV6TED4 | 5DR HB | RN1151V | PN0450 | RN1746H | PN0019W | |
| 09.13~05.21 | 1600 | EC5 | T9 | RN1151VRN1748V | PN0348WPN0450 | PN0472PN0856 | ||
| 06.07~06.11 | 1600 | EP6 | 5-Hatchback | RN1151V | PN0450 | RN1746H | PN0019W | |
| 06.11~06.15 | 1600 | EP6C | 5-Hatchback | RN1151V | PN0450 | RN1746H | PN0019W | |
| 09.07~06.11 | 1600 | EP6DT | 5-Hatchback | RN1151V | PN0450 | RN1746H | PN0019W | |
| 04.08~06.11 | 1600 | EP6DT | SW | RN1151V | PN0450 | RN1746H | PN0019W | |
| 09.07~05.15 | 1600 | TU5JP4 | 5-Hatchback | RN1151V | PN0450 | RN1746H | PN0019W |
| 08.05~12.15 | 1600 | DV6ATED4 | M59 | RN1151VRN1152V | PN0187WPN0182 | RN1860DN1556 | PN0019WFN0600 | |
| 04.12~ | 1600 | DV6AUTED4 | B9 | RN1151V | PN0471 | RN1857H | PN0472 | |
| 04.08~ | 1600 | DV6FD | B9 | RN1151V | PN0471 | RN1857H | PN0472 | |
| 04.08~ | 1600 | TU5JP4 | B9 | RN1151V | PN0471 | RN1857H | PN0472 | |
| 04.08~ | 1600 | TU5JP4B | B9 | RN1151V | PN0471 | RN1857H | PN0472 |
| 02.16~ | 1200 | EB2DT | LCV/microBUS | RN1151V | PN0471 | RN1857HDN1556 | PN0472FN0600 | |
| 04.08~01.09 | 1600 | 1.6 HDi 75 | Fourgon | RN1151V | PN0471 | RN1857H | PN0472 | |
| 01.09~ | 1600 | DV6AUTED4 | Fourgon | RN1151V | PN0471 | RN1857H | PN0472 | |
| 01.09~ | 1600 | DV6BTED4 | Fourgon | RN1151V | PN0471 | RN1857H | PN0472 | |
| 01.09~ | 1600 | DV6DTED | Fourgon Long | RN1151V | PN0471 | RN1857H | PN0472 | |
| 06.08~03.15 | 1600 | DV6ETEDM | B9 | RN1151V | PN0471 | RN1857H | PN0472 |
