ROTOR DISC » RN1746H
Specification
Type
Solid
Outter Ø
249
Num. of holes
4
Height
73
Centering Diameter
56
Pitch Circle Ø
108
Disc Thickness (Max)
9
Drum Ø:
62
Structure Material
G3000
Disc Thickness (Min)
8
Alternative
Cross Reference
CITROEN
1609249980
CITROEN
4249.65
CITROEN
4249.66
PEUGEOT
4249.66
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 12.14~ | 1200 | EB2DTS | NCHNYT HB RHD | RN1151V | PN0471 | RN1746HRN1857H | PN0473 | |
| 11.11~12.14 | 1400 | EP3C | B7 | RN1152V | PN0561 | RN1746H | PN0019W | |
| 10.04~12.10 | 1600 | DV6ATED4 | L_ | RN1746H | ||||
| 07.14~12.20 | 1600 | DV6FD 100 | NC | RN1152V | PN0561 | RN1746H | PN0019W | |
| 06.10~12.15 | 1600 | EP6 | B7 | RN1151V | PN0471 | RN1746H | PN0019W |
| 06.11~06.15 | 1600 | DV6C / 9HR | 5-Hatchback | RN1151V | PN0450 | RN1746H | PN0019W | |
| 06.07~06.11 | 1600 | DV6TED4 | 5DR HB | RN1151V | PN0450 | RN1746H | PN0019W | |
| 06.07~06.11 | 1600 | EP6 | 5-Hatchback | RN1151V | PN0450 | RN1746H | PN0019W | |
| 06.11~06.15 | 1600 | EP6C / 5FS | 5-Hatchback | RN1151V | PN0450 | RN1746H | PN0019W | |
| 09.07~06.11 | 1600 | EP6CDT 156PH | 2-Coupe Cabriolet | RN1748V | PN0348W | RN1746H | PN0019W | |
| 09.07~05.15 | 1600 | EP6CDT 156PH | 5-Hatchback | RN1748V | PN0348W | RN1746H | PN0019W | |
| 03.09~06.11 | 1600 | EP6DT | 2-Coupe Cabriolet | RN1748V | PN0348W | RN1746H | PN0019W | |
| 09.07~06.11 | 1600 | EP6DT | 5-Hatchback | RN1151V | PN0450 | RN1746H | PN0019W | |
| 09.07~05.15 | 1600 | TU5JP4 | 5-Hatchback | RN1151V | PN0450 | RN1746H | PN0019W | |
| 06.07~06.11 | 2000 | DW10BTED4 | 5-Hatchback | RN1748V | PN0348W | RN1746H | PN0019W |
