BRAKE SHOE » FN9991T

Specification

Radius
100
Width
26.4
Thickness
3.5 / 6.1
Pcs In Set
4
Notes
Thickness 3.5 / 6.1 mm South America

Variation

FN9991[NiBK]

Cross Reference

AKEBONO
NN5550
BENDIX AUS
BS5057
FMSI
S1079-1732
KASHIYAMA
K9991
MITSUBISHI
MQ501159
MITSUBISHI
MQ509546
SUZUKI
53200-58M00
SUZUKI
53200-58M00-000
SUZUKI
53200-68L01
SUZUKI
53200-68L10
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.14~ 1400 K14B VC41S RN2245V PN9529 FN9991
03.11~10.15 1200 K12B MB15S RN2245V PN9529 DN1369 FN9991
09.14~ 1400 K14B AVB414 RN2245VRN1787V PN9529 FN9991FN9807
01.11~08.15 1200 K12B MA15S RN2245V PN9529 DN1369 FN9991
09.10~01.17 1600 M16A ZC32S JPN RN2449V PN5562 RN1693DN1369RN1955 PN9808FN9991
09.10~11.16 1200 K12B ZC72S JPN RN29001VRN2245V PN9529 RN1955DN1369 FN9991PN9808
10.09~03.13 1200 K12B ZC72S LHD RN29001V PN5562 DN1369RN1955 FN9991PN9808
03.13~02.17 1200 K12B ZC72S LHD RN29001V PN5562 RN1955DN1369 PN9808FN9991
12.12~ 1400 K14 AZF414 RN2245V PN9529PN5562 RN1955DN1422 PN9808FN9991
03.10~ 1400 K14B AZG414 RN29001V PN5562 RN1693DN1369RN1955 PN9808FN9991
03.10~ 1400 K14B ZC82S LHD RN2245VRN29001V PN5562PN9529 DN1369RN1955RN1693 FN9991PN9808
03.10~03.13 1400 K14B ZC82S RHD RN29001V PN5562 DN1369RN1693RN1955 FN9991PN9808
03.13~02.17 1400 K14B ZC82S RHD RN29001VRN2245V PN9529PN5562 DN1369RN1955RN1693 FN9991PN9808
12.11~ 1600 M16A EZC32S RN2449V PN5562 RN1955RN1693DN1369 FN9991PN9808
10.09~02.13 1600 M16A ZA32S LHD RN2449V PN5562 RN1693DN1369RN1955 FN9991PN9808
10.09~02.13 1600 M16A ZC32S LHD PR RN2449V PN5562 DN1369RN1955RN1693 FN9991PN9808

Exemption from liability: the catalog data is advisory and can be used for reference only
