ROTOR DISC » RN2449V

RN2449V

Specification

Type
Vented
Outter Ø
272
Num. of holes
5
Hole Ø:
12.7
Disc Thickness (Max)
22
Disc Thickness (Min)
20
Height
40
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
150
Front/Rear
Front
Structure Material
G3000

Cross Reference

MARUTI
55311M60M00
SUZUKI
55311-70L00
SUZUKI
55311-72L00
SUZUKI
55311-72R10
SUZUKI
55311-72R10-000
SUZUKI
55311-77M01
SUZUKI
55311M60M00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MARUTI SUZUKI   »   ERTIGA

04.12~10.15 1300 D13A RN2449V PN5562 FN9801
10.15~ 1300 D13A RN2449V PN5562 FN9801
04.12~10.15 1400 K14B RN2449V PN5562 FN9801
11.18~ 1500 K15B RN2449V PN9814 FN9808

SUZUKI   »   Ertiga

03.12~04.18 1400 K14B YZE81S LHD RN2449V PN5544 FN9801
03.12~04.18 1400 K14B ZE81S LHD RN2449V PN5562 FN9801
03.12~04.18 1400 K14B ZE81S RHD RN2449V PN5562 FN9801
08.20~ 1500 K15BT ARK415 LHD RN2449V PN9814 FN9808
08.20~ 1500 K15BT ARK415 RHD RN2449V PN9814 FN9808

SUZUKI   »   Swift

09.10~01.17 1600 M16A ZC32S JPN RN2449V PN5562 DN1369RN1955RN1693 PN9808FN9991

SUZUKI   »   Swift IV

12.11~ 1600 M16A EZC32S RN2449V PN5562 RN1693DN1369RN1955 PN9808FN9991
10.09~02.13 1600 M16A ZA32S LHD RN2449V PN5562 RN1693DN1369RN1955 FN9991PN9808
10.09~02.13 1600 M16A ZC32S LHD PR RN2449V PN5562 RN1955RN1693DN1369 FN9991PN9808
12.11~ 1600 M16A ZC3B RN2449V PN5562 RN1955RN1693 PN9808
