BRAKE SHOE » FN6741
Specification
Radius
147.5
Width
50
Pcs In Set
4
Thickness
3.2 / 6.7
Variation
Cross Reference
BENDIX AUS
BS5018
FIAT
6000609727
GM
94726878
GM
97947766
GM
97947767
GM
97947768
GM
97947802
ISUZU
5-87832-257-0
ISUZU
8-97662-756-0
ISUZU
8-97834-826-0
ISUZU
8-97835-448-0
ISUZU
8-97947-384-0
ISUZU
8-97947-386-0
ISUZU
8-97947-387-0
ISUZU
8-97947-734-0
ISUZU
8-97947-735-0
ISUZU
8-97947-736-0
ISUZU
8-97947-766-0
ISUZU
8-97947-767-0
ISUZU
8-97947-768-0
ISUZU
8-97947-802-0
ISUZU
8-98346-171-0
KASHIYAMA
K4473
KASHIYAMA
K6741
MITSUBISHI
4600A018
MITSUBISHI
4600A106
MITSUBISHI
4600A122
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.17~ | 2500 | LKH | 12L43 LHD | RN2391V | PN2808 | DN1440 | FN6741 | |
| 01.17~ | 2500 | LKH | 12L43 RHD | RN2391V | PN2808 | DN1440 | FN6741 | |
| 01.14~01.17 | 2500 | LKH | LT# | RN1327VRN1635V | PN0822 | DN1440 | FN6741 | |
| 01.17~ | 2500 | LP2 | LT# | RN2391V | PN2808 | DN1440 | FN6741 | |
| 01.12~12.14 | 2500 | LVN | S10 | RN1327V | PN0822 | DN1440 | FN6741 | |
| 01.09~01.16 | 2800 | LWH | LT# | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.12~01.17 | 2800 | LWN | LT# | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.17~01.21 | 2800 | LWN | LT# | RN2391V | PN2808 | DN1440 | FN6741 | |
| 01.12~01.17 | 3600 | LY7 | LT# | RN1635VRN1327V | PN0822 | DN1440 | FN6741 |
| 06.12~ | 2500 | 4JK1-TCY | TFR86 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 06.12~ | 2500 | 4JK1-TCY | TFS86 | RN1635V | PN0822 | DN1440 | FN6741 |
| 04.16~12.19 | 2500 | 4D56 | 5034B5101000 | RN1247V | PN3809 | DN1104 | FN6741 | |
| 03.15~12.19 | 2500 | UAL3217 | 503J85101510 | RN1247V | PN3809 | FN6741 |
| 06.12~12.13 | 2500 | LVN | RG | RN1635V | PN0822 | DN1440 | FN6741 | |
| 11.12~12.20 | 2800 | LWN | RG | RN1635V | PN2808PN0822 | DN1440 | FN6741 |
| 09.19~ | 1900 | RZ4E-TC | TFS87 ML RHD | RN2633V | PN2402PN2401 | DN1440 | FN6741 | |
| 01.16~ | 1900 | RZ4E-TC | TF_87 | PN2403 | DN1440 | FN6741 | ||
| 02.17~ | 1900 | RZ4E-TCX | TFR87 | RN1327V | PN0822 | DN1440 | FN6741 | |
| 02.17~ | 1900 | RZ4E-TCX | TFS87 | RN2416V | PN2401 | DN1440 | FN6741 | |
| 10.06~01.12 | 2500 | 4JA1-T | TFR85 | PN0822 | FN6741 | |||
| 11.19~ | 2500 | 4JK1-TCS | TFR86 INDIA LHD | RN1327V | PN0822 | DN1440 | FN6741 | |
| 03.12~01.16 | 2500 | 4JK1-TCS | TFS86 TH RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 10.16~ | 2500 | 4JK1-TCX | TFR86 RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.16~10.19 | 2500 | 4JK1-TCX | TFS86 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 03.12~01.16 | 2500 | 4JK1-TCX | TFS86 LA RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.17~ | 2500 | 4JK1-TCX | TFS86 LHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 10.18~ | 2500 | 4JK1-TCX | TFS86 LHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 09.15~ | 2500 | 4JK1-TCX | TF_86 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.16~10.19 | 2500 | 4JK1-TCX | TGS86 INDIA | PN2403 | DN1440 | FN6741 | ||
| 03.12~01.16 | 2500 | 4JK1-TCY | TFS86 EU RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 03.12~01.16 | 2500 | 4JK1-TCY | TFS86 ML RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.13~12.16 | 3000 | 4JJ1-T | TFS85JDR | RN1635V | PN0822 | DN1440 | FN6741 | |
| 06.12~05.17 | 3000 | 4JJ1-TCS | TFS85J LHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 06.12~ | 3000 | 4JJ1-TCX | TFR85 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.16~ | 3000 | 4JJ1-TCX | TFS6WF | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.17~ | 3000 | 4JJ1-TCX | TFS85JDL | RN1635V | PN0822 | DN1440 | FN6741 | |
| 07.20~ | 3000 | 4JJ3-TCX | TFS40 RHD | RN2633VRN2416V | PN2401PN2402 | DN1440 | FN6741 |
| 11.17~ | 1900 | RZ4E-TC | UCR | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.14~01.17 | 2500 | 4JK1-TCX | UCS86 | RN1635V | PN0822 | DN1440 | FN6741 |
| 10.18~ | 2500 | 4JK1-TCX | TFS86 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.13~01.14 | 3000 | 4JJ1 | MIDDLE EAST | RN1635V | PN0822 | FN6741 |
| 06.20~ | 1900 | RZ4E-TCX | MP2TFR87 | RN1327V | PN0822 | DN1440 | FN6741 | |
| 06.20~ | 1900 | RZ4E-TCX | MP2TFS87 | RN2416V | PN2401 | DN1440 | FN6741 | |
| 06.20~ | 3000 | 4JJ3-TCX | MP2TFS40 | RN2633VRN2416V | PN2402PN2401 | DN1440 | FN6741 |
| 06.19~ | 2200 | 4N14 | KK6T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 06.19~ | 2200 | 4N14 | KL6T | RN1247VRN3001V | PN3813PN3809 | DN1104 | FN6741 | |
| 06.06~03.15 | 2400 | 4G64 | KA5T | RN1247VRN2360V | PN3809 | DN1104DN1375 | FN6715FN6741 | |
| 12.05~08.06 | 2400 | 4G64 | KB5T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 07.15~05.19 | 2400 | 4N15 | KL1T | RN3001VRN1247V | PN3809PN3813 | DN1104 | FN6741 | |
| 06.19~ | 2400 | 4N15 | KL1T | RN1247VRN3001V | PN3813PN3809 | DN1104 | FN6741 | |
| 01.15~ | 2400 | 4N15 | KL2T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 01.05~04.11 | 2500 | 4D56 | KB4T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 01.05~04.15 | 2500 | 4D56 | KB4T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 04.10~ | 2500 | 4D56 | KB4T | RN1247V | PN3809 | FN6741 | ||
| 01.15~05.19 | 2500 | 4D56 | KL3T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 05.05~03.15 | 2500 | 4D56 | K_4T | RN1247V | PN3809 | FN6741 | ||
| 05.98~08.03 | 2800 | 4M40 | K57T | RN1247V | PN3809 | FN6741 | ||
| 05.05~08.07 | 2800 | 4M40 | KB7T | RN1247V | PN3809 | FN6741 | ||
| 05.07~03.14 | 3200 | 4M41 | KB8T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 05.05~04.15 | 3500 | 6G74 | KA9T | PN3809 | FN6741 | |||
| 05.05~03.15 | 3500 | 6G74 | KB9T | RN1247V | PN3809 | FN6741 |
| 01.08~ | 2500 | 4D56 | KG4W | RN1247V | PN3809 | FN6741 | ||
| 07.08~ | 2500 | 4D56 | KH4W | RN1247V | PN3809 | RN1634V | FN6741PN3391 |
| 10.15~ | 2500 | 4D56 | KR3W | RN1247V | PN3809 | RN3002VDN1104 | FN6741PN3391 | FN0824 |
| 07.08~01.14 | 3000 | 6B31 | KH6W | RN1247V | PN3809 | RN1634V | PN3391FN6741 | FN0568 |
| 10.15~ | 2500 | 4D56 | KS3W | RN1247V | PN3809 | RN3002VDN1104 | FN6741PN3391 | FN0824 |
| 07.08~09.15 | 3500 | 6G74 | KH9W | RN1247V | PN3809 | DN1104RN1634V | FN6741PN3391 | FN0568 |
| 01.15~ | 2400 | 4G64 | KK4T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 01.15~ | 2400 | 4G64 | KL4T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 01.15~ | 2400 | 4N15 | KK1T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 01.15~ | 2400 | 4N15 | KK2T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 05.05~12.14 | 2500 | 4D56 | KB4T | RN1247V | PN3809 | FN6741 | ||
| 01.15~ | 2500 | 4D56 | KK3T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 01.15~ | 2500 | 4D56 | KL3T | RN2360V | PN3809 | DN1104 | FN6741 | |
| 05.15~05.19 | 2500 | 4D56 | KP3T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 01.15~ | 2500 | 4N15 | KL1T | RN1247VRN3001V | PN3809PN3813 | DN1104 | FN6741 | |
| 03.06~ | 3200 | 4M41 | KB8T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 09.06~09.11 | 3500 | 6G74 | KB7T | RN1247V | PN3809 | DN1104 | FN6741 | |
| 03.06~09.11 | 3500 | 6G74 | KB9T | PN3809 | FN6741 | |||
| 03.06~01.15 | 3500 | 6G74 | KB9T | RN1247V | PN3809 | DN1104 | FN6741 |
