ROTOR DISC » RN1635V
Specification
Type
Vented
Outter Ø
300
Num. of holes
6
Disc Thickness (Max)
27
Height
40
Centering Diameter
88
Front/Rear
front
Drum Ø:
195
Pitch Circle Ø
109
Disc Thickness (Min)
25
Structure Material
G3000
Cross Reference
GM
52088568
GM
52091491
GM
94712571
ISUZU
8-97948-806-1
ISUZU
8-97948-807-1
ISUZU
8-98124-663-2
ISUZU
8-98124-663-3
ISUZU
8-98124-663-4
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.14~01.17 | 2500 | LKH | LT# | RN1327VRN1635V | PN0822 | DN1440 | FN6741 | |
| 01.09~01.16 | 2800 | LWH | LT# | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.12~01.17 | 2800 | LWN | LT# | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.12~01.17 | 3600 | LY7 | LT# | RN1635VRN1327V | PN0822 | DN1440 | FN6741 |
| 06.12~ | 2500 | 4JK1-TCY | TFR86 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 06.12~ | 2500 | 4JK1-TCY | TFS86 | RN1635V | PN0822 | DN1440 | FN6741 |
| 01.12~ | 2500 | LVN | 12S06 | RN1635V | PN0822 | RN1636V | PN28002 | FN0734 |
| 08.16~ | 2500 | XLD25 | 31UX | RN1635V | PN0822 | RN1636V | PN28002 | FN0734 |
| 01.12~ | 2800 | LWH | 31UX | RN1635V | PN0822 | RN1636V | PN28002 | FN0734 |
| 01.15~ | 2800 | LWN | 12S06 GR RHD | RN2391VRN1635V | PN0822PN2808 | RN1636V | PN28002 | |
| 01.15~ | 3600 | LFX | 12S06 | RN1635V | PN0822 | RN1636V | PN28002 | |
| 03.12~ | 3600 | LY7 | 12S06 | RN1635V | PN0822 | RN1636V | PN28002 | FN0734 |
| 06.12~12.13 | 2500 | LVN | RG | RN1635V | PN0822 | DN1440 | FN6741 | |
| 06.12~12.20 | 2800 | LWH | RG | RN1635V | PN2808PN0822 | DN1440 | ||
| 11.12~12.20 | 2800 | LWN | RG | RN1635V | PN2808PN0822 | DN1440 | FN6741 |
| 03.12~01.16 | 2500 | 4JK1-TCS | TFS86 TH RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 10.16~ | 2500 | 4JK1-TCX | TFR86 RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.16~10.19 | 2500 | 4JK1-TCX | TFS86 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 03.12~01.16 | 2500 | 4JK1-TCX | TFS86 LA RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.17~ | 2500 | 4JK1-TCX | TFS86 LHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 10.18~ | 2500 | 4JK1-TCX | TFS86 LHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 09.15~ | 2500 | 4JK1-TCX | TF_86 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 03.12~01.16 | 2500 | 4JK1-TCY | TFS86 EU RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 03.12~01.16 | 2500 | 4JK1-TCY | TFS86 ML RHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.13~12.16 | 3000 | 4JJ1-T | TFS85JDR | RN1635V | PN0822 | DN1440 | FN6741 | |
| 06.12~05.17 | 3000 | 4JJ1-TCS | TFS85J LHD | RN1635V | PN0822 | DN1440 | FN6741 | |
| 06.12~ | 3000 | 4JJ1-TCX | TFR85 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.16~ | 3000 | 4JJ1-TCX | TFS6WF | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.17~ | 3000 | 4JJ1-TCX | TFS85JDL | RN1635V | PN0822 | DN1440 | FN6741 |
| 11.17~ | 1900 | RZ4E-TC | UCR | RN1635V | PN0822 | DN1440 | FN6741 | |
| 01.14~12.15 | 2500 | 4JJ1-TCX | UCS85 | RN1635V | PN0822 | RN1636V | PN28002 | FN0734 |
| 01.17~12.17 | 2500 | 4JK1-TCX | UCR86 | RN1635V | PN0822 | RN1636V | PN28002 | FN0734 |
| 01.14~01.17 | 2500 | 4JK1-TCX | UCS86 | RN1635V | PN0822 | DN1440 | FN6741 | |
| 03.17~11.20 | 2500 | 4JK1-TCX | UCS86 RHD MLY | RN1635V | PN0822 | RN1636V | PN28002 | FN0734 |
| 10.18~11.20 | 3000 | 4JJ1-TCX | UCS85 | RN1635V | PN0822 | RN1636V | PN28002 | FN0734 |
