BRAKE SHOE » FN0787

Specification

Radius
114
Width
42
Pcs In Set
4
Thickness
4.6/6.7

Cross Reference

VAG
2Q0 698 525 A
VAG
2Q0 698 525 C
VAG
2Q0 698 525 E
VAG
2Q0 698 525 G
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.18~ 1000 DLAC KJ__SV RN2312V PN0891 DN1532 FN0787
07.18~ 1000 DKLA KJ1 RN2313V PN0148W DN1532 FN0787
09.17~02.24 1000 DBYA A_1_E_ RN2313V PN0148W DN1532 FN0787
07.17~ 1000 CHYC AW1 RN2313V PN0891 RN1084DN1532DN1531 FN0787FN0789PN0019W
06.17~04.21 1000 DLAC AWZ RN2313V PN0148W DN1532 FN0787
12.18~ 1000 CHZL C11 RN2312V PN0891 RN1084 FN0787PN0019W
09.20~ 1000 DLAA C11 RN2312V PN0891 RN1084 PN0019WFN0787
01.20~ 1500 DADA C11 RN2312V PN0891 RN1084 PN0019WFN0787
12.18~ 1600 DGTD C11 RN2312V PN0891 RN1084 PN0019WFN0787
09.21~ 1000 DLAC CS1 RN2312V PN0891 DN1532 FN0787

Exemption from liability: the catalog data is advisory and can be used for reference only
