ROTOR DISC » RN2312V
Specification
Type
Vented
Outter Ø
276
Num. of holes
5
Hole Ø:
15.2
Disc Thickness (Max)
24
Disc Thickness (Min)
21
Height
44
Centering Diameter
65
Pitch Circle Ø
100
Drum Ø:
136
Front/Rear
Front
Structure Material
G3000
Cross Reference
VAG
2Q0 615 301 H
VAG
2Q0 615 301 Q
VAG
2QB 615 301 E
VAG
5QP 615 301 A
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.18~ | 1000 | DKJA | 5DR HB | RN2312V | PN0891 | RN1084 | PN0019W | |
| 09.20~ | 1000 | DLAA | 5DR HB | RN2312VRN2313V | PN33005WPN0891PN0148W | RN1084 | FN0787PN0019WPN0624 | |
| 09.18~ | 1500 | DADA | GBA HB GB5L | RN2312V | PN0891 | RN1084 | PN0019W |
| 04.18~ | 1000 | DKJA | KJ__K_ | RN2312V | PN0891 | RN1084 | PN0019W | |
| 01.18~ | 1000 | DLAC | KJ__SV | RN2312V | PN0891 | DN1532 | FN0787 | |
| 11.17~ | 1600 | CWVA | KJ7_D_ | RN2312V | PN0891 | RN1084 | PN0019W |
| 01.17~ | 1000 | DKJA | KJ1 | RN2312V | PN0891 | RN1084 | PN0019W | |
| 05.17~ | 1600 | CWVA | KJ1_D_ | RN2312V | PN0891 | RN1084 | PN0019W |
| 02.19~ | 1000 | DKLA | NW4 | RN2313VRN2312V | PN0148WPN0891 | RN1084 | PN0019WFN0787 | |
| 02.19~ | 1500 | DADA | NW4 | RN2313VRN2312V | PN0891PN0148W | RN1084 | FN0787PN0019W | |
| 07.19~ | 1500 | DPCA | NW4 | RN2312V | PN0891 | RN1084 | PN0019W | |
| 02.19~ | 1600 | DGTA | NW4 | RN2313VRN2312V | PN0148WPN0891 | RN1084 | PN0019WFN0787 |
| 12.18~ | 1000 | DKJA | HB | RN2312VRN2313V | PN0148WPN0891 | RN1084 | PN0019WFN0787 | |
| 12.18~ | 1000 | DKLA | HB | RN2312VRN2313V | PN0148WPN0891 | RN1084 | FN0787PN0019W | |
| 12.18~ | 1500 | DADA | HB | RN2313VRN2312V | PN0891PN0148W | RN1084 | PN0019WFN0787 | |
| 12.18~ | 1500 | DPCA | HB SG | RN2312V | PN0891 | RN1084 | PN0019W | |
| 12.18~ | 1600 | DGTA | HB | RN2312VRN2313V | PN0148WPN0891 | RN1084 | FN0787PN0019W |
| 12.18~ | 1000 | CHZL | C11 | RN2312V | PN0891 | RN1084 | FN0787PN0019W | |
| 07.19~ | 1000 | DKJA | C11 | RN2312V | PN0891 | RN1084 | PN0019W | |
| 12.18~ | 1000 | DKRF | C11 | RN2312V | PN0891 | RN1084 | PN0019W | |
| 09.20~ | 1000 | DLAA | C11 | RN2312V | PN0891 | RN1084 | PN0019WFN0787 | |
| 01.20~ | 1500 | DADA | C11 | RN2312V | PN0891 | RN1084 | PN0019WFN0787 | |
| 01.19~ | 1600 | CWSA | BF1 | RN2312V | PN0891 | DN1532 | FN0787 | |
| 12.18~ | 1600 | DGTD | C11 | RN2312V | PN0891 | RN1084 | PN0019WFN0787 |
