ROTOR DISC » RN2313V

Specification

Type
Vented
Outter Ø
256
Num. of holes
5
Hole Ø:
15.5
Disc Thickness (Max)
22
Disc Thickness (Min)
19
Height
44.2
Centering Diameter
65
Pitch Circle Ø
100
Drum Ø:
134
Front/Rear
Front
Structure Material
G3000

Cross Reference

VAG
2Q0 615 301 G
VAG
2Q0 615 301 P
VAG
2QB 615 301 D
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.18~ 1000 DKLA KJ1 RN2313V PN0148W DN1532 FN0787
09.17~02.24 1000 DBYA A_1_E_ RN2313V PN0148W DN1532 FN0787
07.17~ 1000 CHYC AW1 RN2313V PN0891 RN1084DN1532DN1531 FN0787FN0789PN0019W
07.17~ 1000 CHYC BZ1 RN2313V PN0891 RN1084 PN0019W
06.17~04.21 1000 DLAC AWZ RN2313V PN0148W DN1532 FN0787

Exemption from liability: the catalog data is advisory and can be used for reference only
