NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1408V

ROTOR DISC » RN1408V

Specification

Type

Vented

Disc Thickness (Max)

25

Num. of holes

5

Height

47.2

Centering Diameter

64

Front/Rear

Front

Outter Ø

296

Disc Thickness (Min)

23

Drum Ø:

142

Pitch Circle Ø

114.3

Structure Material

G3000

Cross Reference

HONDA

45251-TL1-G00

HONDA

45251-TL1-G01

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HONDA » Accord

05.08~07.11	2000	R20A3	CU1 LHD	RN1408V	PN8863	RN1409	PN8864	FN0663
05.08~07.11	2000	R20A3	CU1 RHD	RN1408V	PN8863	RN1409	PN8864
07.11~03.13	2000	R20A3	CU1 RHD	RN1408V	PN8863	RN1409	PN8864
01.08~03.13	2000	R20A3	EURO	RN1406V RN1408V	PN8865 PN8863 PN8465	RN1409 RN1407	PN8864 PN8807
05.08~07.11	2200	N22B1	CU3	RN1408V	PN8863	RN1407	PN8807	FN0663

HONDA » Accord Tourer

09.09~12.10	2000	R20A3	EURO	RN1408V	PN8863	RN1409	PN8864
07.08~06.15	2200	N22B1	CW3	RN1406V RN1408V	PN8863 PN8865	RN1407	PN8807	FN0663
09.09~10.10	2200	N22B1	EURO	RN1408V	PN8863	RN1407	PN8807	FN0663
