ROTOR DISC » RN1458V

Specification

Type
Vented
Disc Thickness (Max)
22
Num. of holes
4
Height
49.3
Centering Diameter
55
Front/Rear
Front
Pitch Circle Ø
100
Outter Ø
254.9
Drum Ø:
131
Disc Thickness (Min)
20
Structure Material
G3000

Cross Reference

OEM
4351212650
TOYOTA
43512-02050
TOYOTA
43512-12610
TOYOTA
43512-12611
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.00~08.08 1300 2NZ-FE NZE120 RN1458V PN1472 FN2342
08.00~08.07 1300 2NZ-FE NZE120L RN1458V PN1472 DN1206 FN2342
08.00~08.08 1300 2NZ-FE NZE120R RN1198VRN1458V PN1472 RN1308DN1206 PN1454FN2342 FN0614
08.00~09.06 1500 1NZ-FE NZE121 RN1458V PN1472 DN1206 FN2342
08.00~09.06 1500 1NZ-FE NZE121G RN1458V PN1472 DN1206 FN2342
01.01~09.06 1500 1NZ-FE NZE121 RN1458V PN1472 DN1206 FN2342
05.01~03.03 1500 1NZ-FE NZE121N RN1458VRN1198V PN1472 DN1206 FN2358FN2342

Exemption from liability: the catalog data is advisory and can be used for reference only
