NiBK Brakes:: Application Cross Reference and Image for NiBK : BRAKE SHOE : FN11001

BRAKE SHOE » FN11001

Specification

Radius

145

Width

52

Thickness

7.3

Pcs In Set

4

Variation

Cross Reference

FMSI

S1003

HYUNDAI

58305-4HA00

KASHIYAMA

K11228

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » Grand Starex

08.15~12.17

2500

D4CB A2

WGN 12P RHD

RN1457V

PN0458

RN1656V

PN0457 FN11001

FN0715

HYUNDAI » H1 Starex

05.07~08.15	2400	G4KG	VAN LONG - 3P LHD	RN1457V	PN0458	DN1498	FN11001
05.07~08.15	2400	G4KG	VAN LONG - 3P RHD	RN1457V	PN0458	DN1498	FN11001
12.17~	2500	D4BH (4D56)	WAGON LONG - 12P LHD	RN1457V	PN0458	DN1498	FN11001
08.15~05.18	2500	D4CB A2	VAN LONG - 3P	RN1457V	PN0458	DN1498	FN11001
05.18~	2500	D4CB A2	VAN LONG - 3P	RN1457V	PN0458	DN1498	FN11001
12.17~	2500	D4CB A2	WAGON LONG - 12P RHD	RN1457V	PN0458	DN1498	FN11001

HYUNDAI » H1 Starex [H1 Cargo] 07

05.07~08.15	2400	G4KG	WAGON LONG - 12P RHD	RN1457V	PN0458	DN1498 RN1656V	FN11001 PN0457	FN0715
05.07~08.15	2400	G4KG	WAGON LONG - 9P LHD	RN1457V	PN0458	DN1498	FN11001
05.07~08.15	2500	4D56	WAGON LONG - 12P	RN1457V	PN0458	DN1498	FN11001
05.07~08.15	2500	4D56	WAGON LONG - 9P	RN1457V	PN0458	DN1498	FN11001
05.07~08.15	2500	D4BH (4D56)	VAN LONG - 3P	RN1457V	PN0458	DN1498	FN11001
05.07~08.15	2500	D4CB A2	WAGON LONG - 12P	RN1457V	PN0458	DN1498 RN1656V	PN0457 FN11001	FN0715
05.07~08.15	2500	D4CB A2	WAGON LONG - 8P	RN1457V	PN0458	DN1498	FN11001
