BRAKE SHOE » FN11001T

Specification

Radius
145
Width
52
Thickness
9
Pcs In Set
4
Notes
Thickness 9.0 mm South America

Cross Reference

FMSI
S1003
HYUNDAI
58305-4HA00
KASHIYAMA
K11228
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.15~12.17 2500 D4CB A2 WGN 12P RHD RN1457V PN0458 RN1656V PN0457FN11001 FN0715
05.07~08.15 2400 G4KG VAN LONG - 3P LHD RN1457V PN0458 DN1498 FN11001
05.07~08.15 2400 G4KG VAN LONG - 3P RHD RN1457V PN0458 DN1498 FN11001
08.15~05.18 2500 D4CB A2 VAN LONG - 3P RN1457V PN0458 DN1498 FN11001
05.18~ 2500 D4CB A2 VAN LONG - 3P RN1457V PN0458 DN1498 FN11001
12.17~ 2500 D4CB A2 WAGON LONG - 12P RN1457V PN0458 DN1498 FN11001
05.07~08.15 2400 G4KG WAGON LONG - 12P RHD RN1457V PN0458 DN1498RN1656V FN11001PN0457 FN0715
05.07~08.15 2400 G4KG WAGON LONG - 9P LHD RN1457V PN0458 DN1498 FN11001
05.07~08.15 2500 4D56 WAGON LONG - 12P RN1457V PN0458 DN1498 FN11001
05.07~08.15 2500 4D56 WAGON LONG - 9P RN1457V PN0458 DN1498 FN11001
05.07~08.15 2500 D4BH (4D56) VAN LONG - 3P RN1457V PN0458 DN1498 FN11001
05.07~08.15 2500 D4CB A2 WAGON LONG - 12P RN1457V PN0458 DN1498RN1656V PN0457FN11001 FN0715
05.07~08.15 2500 D4CB A2 WAGON LONG - 8P RN1457V PN0458 DN1498 FN11001

Exemption from liability: the catalog data is advisory and can be used for reference only
