ROTOR DISC » RN1457V
Specification
Type
Vented
Disc Thickness (Max)
30
Num. of holes
6
Height
52.5
Centering Diameter
96.2
Front/Rear
Front
Pitch Circle Ø
139.7
Outter Ø
300
Drum Ø:
163
Hole Ø:
12.5
Disc Thickness (Min)
28,4
Structure Material
G3000
Cross Reference
HYUNDAI
51712-4H000
HYUNDAI
51712-4H500
HYUNDAI / KIA
517124H500
years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
---|
05.07~ | 2400 | G4KG | TQ07 | RN1457V | PN0458 | RN1656V | PN0457 | FN0715 |
05.07~08.15 | 2500 | D4CB A2 | TQ07 | RN1457V | PN0458 | RN1656V | PN0457 | FN0715 |
05.07~08.15 | 2500 | D4CB A2 | WAGON LONG - 11P | RN1457V | PN0458 | RN1656V | PN0457 | FN0715 |
08.15~12.17 | 2500 | D4CB A2 | WGN 12P LHD | RN1457V | PN0458 | RN1656V | PN0457 | FN0715 |
08.15~12.17 | 2500 | D4CB A2 | WGN 12P RHD | RN1457V | PN0458 | RN1656V | PN0457FN11001 | FN0715 |
05.07~08.15 | 2400 | G4KG | VAN LONG - 3P LHD | RN1457V | PN0458 | DN1498 | FN11001 | |
05.07~08.15 | 2400 | G4KG | VAN LONG - 3P RHD | RN1457V | PN0458 | DN1498 | FN11001 | |
12.17~ | 2500 | D4BH (4D56) | WAGON LONG - 12P LHD | RN1457V | PN0458 | DN1498 | FN11001 | |
08.15~05.18 | 2500 | D4CB A2 | VAN LONG - 3P | RN1457V | PN0458 | DN1498 | FN11001 | |
05.18~ | 2500 | D4CB A2 | VAN LONG - 3P | RN1457V | PN0458 | DN1498 | FN11001 | |
12.17~ | 2500 | D4CB A2 | WAGON LONG - 12P RHD | RN1457V | PN0458 | DN1498 | FN11001 | |
12.17~ | 2500 | D4CB A2 | WAGON LONG - 8P | RN1457V | PN0458 | RN1656V | PN0457 | FN0715 |
05.07~08.15 | 2400 | G4KG | WAGON LONG - 12P LHD | RN1457V | PN0458 | RN1656V | PN0457 | FN0715 |
05.07~08.15 | 2400 | G4KG | WAGON LONG - 12P RHD | RN1457V | PN0458 | RN1656VDN1498 | FN11001PN0457 | FN0715 |
05.07~08.15 | 2400 | G4KG | WAGON LONG - 9P LHD | RN1457V | PN0458 | DN1498 | FN11001 | |
05.07~08.15 | 2500 | 4D56 | WAGON LONG - 12P | RN1457V | PN0458 | DN1498 | FN11001 | |
05.07~08.15 | 2500 | 4D56 | WAGON LONG - 9P | RN1457V | PN0458 | DN1498 | FN11001 | |
05.07~08.15 | 2500 | D4BH (4D56) | VAN LONG - 3P | RN1457V | PN0458 | DN1498 | FN11001 | |
05.07~08.15 | 2500 | D4CB A2 | VAN LONG - 3P | RN1457V | PN0458 | DN1498RN1656V | PN0457FN11002 | FN0715 |
08.15~05.18 | 2500 | D4CB A2 | VAN LONG - 6P | RN1457V | PN0458 | RN1656V | PN0457 | FN0715 |
05.07~08.15 | 2500 | D4CB A2 | WAGON LONG - 12P | RN1457V | PN0458 | DN1498RN1656V | PN0457FN11001 | FN0715 |
05.07~08.15 | 2500 | D4CB A2 | WAGON LONG - 8P | RN1457V | PN0458 | DN1498 | FN11001 | |
08.15~05.18 | 2500 | D4CB A2 | WAGON LONG - 8P | RN1457V | PN0458 | RN1656V | PN0457 | FN0715 |
